Mimosa Networks

Part:
100-00036-HW

Mimosa B11 11 Ghz 1.5Gbps capable PtP backhaul, connectorized

$1,909.99
$2,099.00
Condition:
New

PRODUCT SPECIFICATIONS

The Mimosa B11 backhaul radio is designed for the modern Internet era, adapting instantly to variable upstream and downstream bandwidth requirements. The B11 is fiber-ready—simply add your preferred SFP module and you’ll be lit up with gigabit fiber speeds. If you are not quite ready for fiber, the B11 also comes with a standard gigabit power-over-ethernet connection. We’ve simplified the licensing process and offer instant visibility into the FCC ULS database to quickly assess surrounding links, providing an early indication of coordination viability.
A single B11 can support an entire 10.7 – 11.7 GHz band, maximizing your ability to find a clear, licensable channel.

  • Superior Performance
    • Our speeds will blow you away. With up to 1.5 Gbps aggregate speed and under 1 ms latency, high performance has never been this affordable. The B11 has the lowest cost per Mpbs in the industry with link distances over over 100 km.
  • Ultra Rugged
    • Carrier grade IP67 design allows the B11 to withstand the harshest of environmental conditions.
  • Night and Day
    • The B11 dynamically adapts to bandwidth demand using auto-TDMA technology, maximizing spectrum utilization throughout the day.
  • Monitor with Ease
    • Assessing link health and identifying potential problems has never been easier. Links are continuously monitored by our Mimosa Cloud service with rich data collection and analysis.
  • Right on Target
    • We’ve taken the guesswork out of antenna aiming by adding 2.4 GHz WiFi right in the radio, turning any smartphone into the most sophisticated aiming tool on the planet.
    • You can instantaneously view radio details and target signal levels with the most precise aiming technology in the industry.

Dimensions

  • 260 mm (10.2”) x 158 mm (9.6”) x 70 mm (2.8”)

Weight

  • 2.5 kg (4.5 lbs)

Technical Description

  • Performance
    • Max Throughput: Up to 1.5 Gbps IP aggregate UL/DL (1.7 Gbps PHY)
    • Low Latency: <1 ms
    • Supported MAC: TDMA, TDMA-FD
  • Radio
    • MIMO & Modulation: 4x4:4 MIMO OFDM up to 256 QAM
    • Bandwidth: Single or dual 20/40/80 MHz channels
    • Frequency Range:
      • 10000–11700 MHz
        • Restricted by country of operation
    • Max Output Power: 27 dBm
    • Sensitivity ( MCS 0 ):
      • -87 dBm @ 80 MHz
      • -90 dBm @ 40 MHz
      • -93 dBm @ 20 MHz
  • Power
    • Max Power Consumption: 30W
    • System Power Method: 48 V DC 802.3 at compliant power injectors
    • System Lightning & ESD Protection: 6 kV
    • PoE Power Supply: Passive POE compliant, 48-56 V Power over Ethernet supply with IEC61000-4-5 surge protection
  • Features
    • Gigabit Ethernet: 10/100/1000-BASE-T
    • Fiber Capable: SFP Cage included Radio accepts either copper Ethernet or SFP but does not support simultaneous operation
    • Dual Protocol Operation:
      • 2 dual-stream radios operating on non-contiguous frequencies allow for traditional FDD-like performance or TDMA
      • Automatic load balancing of traffic across 4 total MIMO streams with individual stream encoding up to 256 QAM
    • Management Services:
      • Mimosa cloud monitoring and management; SNMPv2 & Syslog legacy monitoring; HTTPS; HTML 5 based Web UI; 2.4 GHz 802.11b/g/n radio for local management access
    • Smart Antenna Alignment: Hands-free, dedicated 2.4 GHz WiFi management radio alignment tool
    • Smart Spectrum Management:
      • Active scan monitors/logs ongoing RF interference across channels (no service impact); Dynamic auto-optimization of channel and bandwidth use
    • Security: 128-bit AES PSK with hardware acceleration
    • QoS: Supports 4 pre-configured QoS levels
    • GPS Location: GNSS-1 (GPS + GLONASS)
    • Colocation Synchronization: 1PPS GPS TX/RX synchronization for colocated co-channel radios; Adjustable up/downstream bandwidth radio
  • Regulatory and Compliance
    • Approvals: FCC Part 101 and EN 302 217
    • RoHS Compliance: Yes
    • Safety: UL/EC/EN/ 60950-1 + CSA-22.2
  • Physical
    • Enclosure Characteristics: Outdoor UV stabilized plastic Aluminum mounting panel
    • Wind Survivability: 200 km/h (125 mph)
    • Wind Loading: 9.8 kg @ 160 km/h (21.8 lbs @ 100 mph)
    • Mounting: Direct mount to compatible antenna
    • Antenna Connection: Direct connect to circular dual polarized antenna
    • Network Interfaces: Single connection ethernet or fiber
  • Environmental
    • Outdoor Ingress Protection Rating: IP67
    • Operating Temperature: -40°C to +55°C (-40°F to 131°F)
    • Operating Humidity: 5 to 100% condensing
    • Operating Altitude: 4420 m (14500’) maximum
    • Shock & Vibration: ETS 300-019-2-4 class 4M5

More Information

MFRPartNum:
B11
Datasheet:
