PRODUCT SPECIFICATIONS
RUT300 - INDUSTRIAL ETHERNET ROUTER
The RUT300 is a small, but powerful Ethernet router perfect for challenging industrial networking tasks as well as general networking applications. Five Ethernet ports, two configurable digital Inputs/Outputs, and a USB port to easily connect the various equipment to the internet. Preconfigured Firewall for immediate security and multiple top-rated VPNs. Passive PoE helps to reduce deployment complexity. Economical but a feature-rich industrial device that comes with all the benefits of RutOS and Remote Management System (RMS).
Features
- INTERFACES: 5 x Fast Ethernet ports (10/100 Mbps). 2 x Configurable digital Inputs/Outputs and USB 2.0
- DURABILITY: Aluminum housing, which is capable to withstand harsh environments
- VPN: Numerous VPN services including OpenVPN, IPsec, PPTP, L2TP & DMVPN, L2TP, DMVPN, Stunnel and others
- RMS: For remote management, access & VPN services
Dimensions
- 100 x 30 x 85 mm
Weight
- 229 g
Technical Description
- ETHERNET
- WAN: 1 x WAN port 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX
- LAN: 4 x LAN ports, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX crossover
- NETWORK
- Routing: Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing
- VoIP passthrough support: H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
- Firewall: Port forward, traffic rules, custom rules
- Network backup: VRRP, Wired options, each of which can be used as an automatic Failover
- Load balancing: Balance Internet traffic over multiple WAN connections
- SSHFS: Possibility to mount remote file system via SSH protocol
- SECURITY
- Authentication: Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & Login attempts block
- Firewall: Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T
- Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
- Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter
- VPN
- OpenVPN: Multiple clients and a server can run simultaneously, 27 encryption methods
- GRE: GRE tunnel, GRE tunnel over IPsec support
- PPTP, L2TP: Client/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support
- Stunnel: Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code
- SSTP: SSTP client instance support
- ZeroTier: ZeroTier VPN client support
- WireGuard: WireGuard VPN client and server support
- PHYSICAL INTERFACES
- Ethernet: 5 x RJ45 ports, 10/100 Mbps
- I/Os: 2 x Configurable I/O pins on 4-pin power connector
- Status LEDs: 5 x ETH status, 1 x Power
- Power: 1 x 4-pin power connector
- USB: 1 x USB A port for external devices
- Reset: Reboot/User default reset/Factory reset button
More Information
MFRPartNum:
RUT300
