PRODUCT SPECIFICATIONS
TP-Link TL-WR902AC AC750 Dual-Band Wi-Fi Travel Router
The TP-Link TL-WR902AC is a compact wireless travel router designed to share an available internet connection with personal devices. Its portable design and USB power input make it suitable for hotel stays, temporary workspaces and everyday home networking.
Dual-band Wi-Fi provides connection rates of up to 300 Mbps on 2.4 GHz and 433 Mbps on 5 GHz. Five operating modes allow the router to create a wireless network from Ethernet, share an existing Wi-Fi connection, extend coverage or connect an Ethernet device to Wi-Fi.
Key Features
- AC750 dual-band Wi-Fi with IEEE 802.11ac support.
- Up to 300 Mbps on 2.4 GHz and 433 Mbps on 5 GHz.
- Router, Hotspot/WISP, Access Point, Range Extender and Client modes.
- One 10/100 Mbps RJ45 WAN/LAN port.
- USB 2.0 port for supported storage-sharing functions.
- External 5 V DC, 2 A power supply.
- Compact 74 x 67 x 22 mm enclosure.
Flexible Operating Modes
- Router: Share an Ethernet internet connection over Wi-Fi.
- Hotspot/WISP: Share an available wireless internet connection through a local network.
- Access Point: Add Wi-Fi access to an existing wired network.
- Range Extender: Extend an existing wireless network.
- Client: Connect an Ethernet-equipped device to an existing Wi-Fi network.
Ethernet and USB Connectivity
The single RJ45 port operates as WAN or LAN according to the selected mode. It supports Fast Ethernet at up to 100 Mbps. The separate USB 2.0 port supports file sharing with compatible USB storage and can supply up to 5 V, 1 A for charging one device.
Portable Power
Use the supplied power adapter or a suitable USB power source capable of meeting the router's 5 V DC, 2 A requirement. A portable power bank is an external accessory; the router does not provide its own cellular internet service.
Network Management
Configure the router through its web interface. Available functions include wireless security, DHCP and network controls, with options depending on operating mode, hardware revision and firmware.
Ideal Applications
- Sharing an available hotel Ethernet connection with wireless devices.
- Creating a temporary network while traveling.
- Connecting a wired desktop, television or game console to Wi-Fi.
- Adding wireless access to a wired network.
- Extending Wi-Fi coverage in a small indoor workspace.
Compatible Products
The TL-WR902AC works with Wi-Fi clients using its supported 2.4 GHz or 5 GHz standards and security settings. TP-Link specifically identifies the following product families as supported wireless clients:
- Google Chromecast: Connect through a supported Wi-Fi band and compatible authentication settings.
- Amazon Fire TV Stick: Connect through a supported Wi-Fi band and compatible authentication settings.
Client mode also allows an Ethernet-equipped desktop, smart TV or game console to connect to an existing Wi-Fi network. The connected device must support standard Ethernet networking.
Important: Compatibility with a product family does not guarantee every generation, hotel login system or network configuration. Captive portals and upstream access restrictions may require additional authentication. USB cellular-modem support depends on region, hardware revision, firmware and the specific modem; do not assume that any USB modem will work.
Technical Specifications
General
- Brand / Manufacturer: TP-Link
- Model / MPN: TL-WR902AC
- Product Type: Portable dual-band wireless travel router
- Wireless Class: AC750 / Wi-Fi 5
- Operating Modes: Router, Hotspot/WISP, Access Point, Range Extender and Client
Wireless
- Frequency Bands: 2.4 GHz and 5 GHz
- 2.4 GHz Standards: IEEE 802.11b/g/n
- 5 GHz Standards: IEEE 802.11a/n/ac
- Maximum 2.4 GHz Link Rate: 300 Mbps
- Maximum 5 GHz Link Rate: 433 Mbps
- Antennas: Internal
- Documented Security: WEP, WPA and WPA2; WPA-PSK/WPA2-PSK
Ethernet and USB
- Ethernet Interface: One RJ45 10/100 Mbps WAN/LAN port
- Port Role: Determined by operating mode
- USB Data Interface: One USB 2.0 port
- Storage Functions: File sharing, FTP server and media server, depending on firmware and mode
- Listed Storage Formats: FAT32 and NTFS
Power
- External Power Supply: 5 V DC, 2 A
- Power Input: USB power connection
- USB Charging Output: Up to 5 V, 1 A through the USB sharing port
Management
- Configuration: Web interface
- App Management: TP-Link Tether, subject to hardware and firmware support
- Network Functions: DHCP, access control and guest networking, depending on mode and firmware
Physical and Environmental
- Dimensions: 74 x 67 x 22 mm (W x D x H)
- Manufacturer-Listed Weight: 56.7 g
- Operating Temperature: 0°C to 40°C
- Storage Temperature: -40°C to 70°C
- Operating Humidity: 10%–90%, non-condensing
- Storage Humidity: 5%–90%, non-condensing
Included Parts
- TL-WR902AC travel router
- Power adapter
- RJ45 Ethernet cable
- Quick installation guide
Download TP-Link TL-WR902AC V4 AC750 Travel Router Datasheet (PDF)
