TP-Link RE200 AC750 Wi-Fi Range Extender Dual Band Mesh WiFi Coverage 750Mbps Ethernet Port Mini Wall-Mount

TP-Link RE200 AC750 Mesh Wi-Fi Range Extender

Place the RE200 between your wireless router and wireless devices, expanding WiFi coverage while eliminating WiFi dead zones. Enjoy a seamless wireless network throughout your home or office. The dual bands WiFi up to 750Mbps not only help extend to 2,000 sq.ft. (185 m2), but also make good use of your high ISP speed — ideal for HD video streaming, online gaming and other bandwidth-intensive tasks.

Key Features

• Boosts wireless signal to previously unreachable or hard-to-wire areas flawlessly.
• Creates a Mesh network by connecting to a TP-Link OneMesh™ router for seamless whole-home coverage.
• Compatible with 802.11 b/g/n and 802.11ac Wi-Fi devices
• Dual band speeds up to 750 Mbps
• Miniature size and wall-mounted design make it easy to deploy and move flexibly
• Ethernet port allows the Extender to function as a wireless adapter to connect wired devices

Technical Specification

• Hardware Features:
  • Standards and Protocols: IEEE802.11ac,IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
  • Plug Type: EU, UK, US, AU
  • Interface: 1× 10/100Mbps Ethernet Port (RJ45)
  • Button: RE (Range Extender) Button, Reset Button
  • Input Power: 100-240V~50/60Hz
  • Max. Power Consumption: About 6.5W
  • Dimensions ( W x D x H ): 4.3x 2.6 x 3.0in. (110.0 x 65.8 x 75.2mm)
  • Antenna: 3 x internal
• Wireless Features:
  • Wireless Standards:
    • IEEE 802.11a/n/ac 5GHz
    • IEEE 802.11b/g/n 2.4GHz
  • Frequency: 2.4GHz & 5GHz
  • Signal Rate:
    • 5GHz:Up to 433Mbps
    • 2.4GHz:Up to 300Mpbs
  • Working Modes: Range Extender/Access Point
  • Reception Sensitivity:
    • 2.4G:
      • 270M: -70dBm@10% PER
      • 130M: -70dBm@10% PER
      • 108M: -73dBm@10% PER
      • 54M: -75dBm@10% PER
      • 11M: -86dBm@8% PER
      • 6M: -92dBm@10% PER
      • 1M: -94dBm@8% PER
    • 5G:
      • 390M: -60dBm@10% PER
      • 29.3M: -83dBm@10% PER
      • 180M: -64dBm@10% PER
      • 13.5M: -87dBm@10% PER
      • 78M: -68dBm@10% PER
      • 6.5M: -90dBm@10% PER
      • 54M: -75dBm@10% PER
      • 6M：-90dBm@10% PER
    • Wireless Modes: Range Extender/Access Point
    • Wireless Functions:
      • WMM (Wi-Fi Multimedia)
      • Wireless Statistic
      • Domain Login Function
    • Wireless Security:
      • 64/128/152-bit WEP
      • WPA-PSK / WPA2-PSK
    • Transmission Power : < 20 dBm (EIRP)
    • Mesh Technology: EasyMesh
  • Other:
    • Network Services Enabled by Default:
      • Web Server - Manage and configure device through web (HTTP/HTTPS)
        • Port: 80/443 - Protocol: TCP
      • DHCP Server - IP address assignment (DHCP)
        • Port: 67 - Protocol: UDP
      • App management - Manage and configure device through app
        • Port: 20001 - Protocol: TCP
        • Port: 20002 - Protocol: UDP
  • Others:
    • Certification: CE, FCC, RoHS
    • Package Content:
      • AC750 Wi-Fi Range Extender RE200
      • Quick Installation Guide
    • System Requirements: Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
    • Environment:
      • Operating Temperature: 0°C~40°C (32°F~104°F)
      • Storage Temperature: -40°C~70°C (-40°F~158°F)
      • Operating Humidity: 10%~90% non-condensing
      • Storage Humidity: 5%~90% non-condensing
