PRODUCT SPECIFICATIONS
TP-LINK HC220-G5 Home Mesh WiFi System
A reliable IP phone for small business users, the GXP1620/1625 delivers a suite of powerful VoIP features in an easy-to-use fashion with a modern design. The GXP1620/1625 offers support for up to 2 lines and features full HD audio on both the speaker and handset to allow users to communicate with the utmost clarity. The GXP1625 features built-in PoE while the GXP1620 does not. These features allow the GXP1620/1625 to be a high-quality and easy-to-use small business IP phone.
Key Features
- Faster WiFi 5 Connections: Speeds up to 1200 Mbps—867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz.
- Boosted Seamless Coverage: Client Steering & Band Steering intelligently connect devices to the mesh AP with the strongest signal – ensuring connectivity regardless of physical location. A unified wireless network (SSID) is used throughout the whole home – providing a truly seamless wireless experience.***
- Enhanced Security: WPA3 encryption, Multi-SSID, VPN, and Parental Controls provide personalized and safer online experience.
- EasyMesh Compatible: Create a smart mesh network with seamless coverage and greater flexibility.
- Easy Cloud Management: Compatible with TAUC (TP-Link Aginet Unified Cloud) to allow service providers to manage multiple devices remotely.
Technical Specifications
- HARDWARE FEATURES:
- Interface:
- 3× Gigabit Ports
- 1 Port supports WAN/LAN auto-sensing
- Button:
- Reset Button
- WPS Button
- External Power Supply: 12 VDC/1.0 A
- Dimensions (W x D x H): 3.9 x 3.9 x 3.3 in (100 x 100 x 85 mm)
- Interface:
- WIRELESS FEATURES:
- Wireless Standards: Wi-Fi 5
- IEEE 802.11 a/n/ac 5 GHz
- IEEE 802.11 b/g/n 2.4 GHz
- Frequency: 2.4 GHz and 5 GHz
- Signal Rate: AC1200
- 5 GHz: 867 Mbps (802.11ac)
- 2.4 GHz: 300 Mbps (802.11n)
- Transmit Power:
- FCC: <30 dBm (2.4 GHz), <30 dBm (5 GHz)
- CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz)
- Wireless Security: WPA-PSK/WPA2-PSK/WPA3 Personal encryptions
- Multi-SSID:
- 4 × 5 GHz Multi-SSID
- 4 × 2.4 GHz Multi-SSID
- Wireless Standards: Wi-Fi 5
- SOFTWARE FEATURES:
- Quality of Service: WMM
- Advanced Features: Parental Controls, QoS (Quality of Service), Address Reservation, Port Forwarding, WiFi Schedule
- WAN Type: Dynamic IP/Static IP/PPPoE
- Management: Local Management, TAUC Cloud Management
- Firewall Security: SPI Firewall
- Protocols: Supports IPv4 and IPv6
- Working Modes:
- Router Mode
- Access Point Mode
- OTHERS:
- Package Contents:
- 1 x HC220-G5 Unit
- 1 x RJ45 Ethernet Cable
- 1 x Power Adapter
- 1 x Quick Installation Guide
- Smartphone/Tablet Requirements:
- Android 4.4 or later
- iOS 9.0 or later
- Certifications: CE, FCC
- Environment:
- Operating Temperature: 0℃–40℃ (32℉ –104℉)
- Storage Temperature: -40℃–60℃ (-40℉ –140℉)
- Operating Humidity: 10%–90% non-condensing
- Storage Humidity: 5%–90% non-condensing
- Package Contents:
More Information
MFRPartNum:
HC220-G5
