PRODUCT SPECIFICATIONS
D-Link DIR-X1550 Mesh Wi-Fi 6 Router
The custom-designed N5-X modular antennas are specifically optimized for C5x extended frequency support. Each antenna in the N5-X family is optimized to isolate noise with incredible sidelobe rejection. The C5x’s native 8 dBi gain can be increased to 12, 16, 20, or 25 dBi using Mimosa’s modular N5-X twist-on antennas, offering the ease and simplicity of integrated radios, but with so much more flexibility.
Key Features
- Next gen WiFi 6: Wi-Fi 6 technology achieves faster speeds, greater capacity & less network congestion when compared to older wireless generations.
- 38 percent faster: Lag-free gaming and streaming with x2 bandwidth, 1024-QAM and x4 simultaneous streams that boost speeds up to 1500 Mbps.
- Increased capacity: OFDMA provides higher capacity to connect more devices around your home, allowing you to connect more and congest less.
- More efficient: Built-in power amplifiers, beamforming, MU-MIMO, OFDMA push your internet to work smarter.
- WPA3™ Secure Encryption: The most advanced Wi-Fi Alliance security standard available with a stronger encryption algorithm.
- Parental Controls: Assign devices to family members’ profiles to individually block devices and websites, set schedules for access, and turn off Wi-Fi.
- Voice Control: Take control of your network using voice commands for Amazon Alexa and Google Assistant.
- Test Internet Speed: Find out your true internet speed using the industry-leading platform via the free D-Link Wi-Fi app, measuring straight from your router.
Technical Specifications
- General:
- Device Interfaces:
- One 10/100/1000 Mbps Gigabit Ethernet WAN port
- Three 10/100/1000 Mbps Gigabit Ethernet LAN ports
- IEEE 802.11 ax/ac/n/g/b/a wireless LAN
- LEDs:
- Power: 2.4 G Wi-Fi
- Internet: 5 G Wi-Fi
- Antenna Type: Four external antennas
- Wi-Fi Data Rate:
- 2.4 GHz - up to 300 Mbps
- 5 GHz - up to 1200 Mbps
- Standards:
- IEEE 802.11ax
- IEEE 802.11b
- IEEE 802.11ac
- IEEE 802.11a
- IEEE 802.11n
- IEEE 802.3u
- IEEE 802.11g
- IEEE 802.3ab
- Minimum Requirements:
- Windows 10/8.1/8/7/Vista or MAC OS X 10.6 or higher
- Supports Internet Explorer 10, Firefox 28.0, Chrome 28.0, Safari 6.0, and up Network Interface Card
- Cable/DSL modem or other Internet service provider equipment with Ethernet port
- Device Interfaces:
- Funcionality:
- Security:
- WPA
- WPA3 (Wi-Fi Protected Access)
- WPA2 (Wi-Fi Protected Access)
- WPS (Wi-Fi Protected Setup)
- Advanced Features:
- D-Link Wi-Fi Mesh
- Ookla SpeedTest
- D-Link Wi-Fi App Setup and Configuration
- QoS (Quality of Service)
- DMZ (De-militarized Zone)
- Firewall - Network Address Translation (NAT)
- Guest Zone
- Multicast Support
- Voice Assistant
- Security:
- Physical:
- Dimensions: 174 x 139 x 60.3 mm
- Weight: 280 g
- Power Adaptor:
- Input: 100 to 240 V AC, 50 / 60 Hz
- Output: 12 V DC, 1 A
- Temperature:
- Operating: 0 to 40 °C (32 to 104 °F)
- Storage: -20 to 65 °C (-4 to 149 °F)
- Humidity:
- Operating: 10% to 90% non-condensing
- Storage: 5% to 95% non-condensing
- Certifications:
- FCC
- IC
- CE
More Information
MFRPartNum:
DIR-X1550
datasheet:
