PRODUCT SPECIFICATIONS
MC4-3-1-KIT - PV 3:1 M+F Adapter Kit
The Tycon SolarĀ® MC4-3-1-Kit is an industry standard PV connector adapter kit. It is used to combine the outputs of three panels into one cable. There are two adapters in each kit, one with Male output and one with female output. The IP67 UV Protected weatherproof connectors are designed for outdoor use in harsh environments.
Features
- Combine Two Connections to One
- Rated for up to 1000VDC @ 30A
- IP67 Weatherproof Rating
Applications
- Remote Power Systems
- Solar Power Applications
Dimensions
- 107.5mm x 63mm (4.2 x 2.5ā)
Weight
- 120g (0.26lb )
Technical Description
- Model: MC4-3-1-KIT
- Connector System (Pin): 4mm2
- Rated Voltage: 1000 VDC
- Rated Solar Current: 30A Max
- Test Voltage: 6KV (50hz, 1min)
- Contact Resistance: <0.5 mā¦
- Contact Material: Copper, Tin Plated
- Insulation Material: PPO
- Flammability Rating: UL-94-V0
- Environmental Protection: IP67
- Salt Spray: IEC 60068-2-52
- Certifications: CE (EN50521:2008), RoHS, CB
- Safety: Class II
- Operating Temp: -40Ā°C to 75Ā°C (-40Ā°F to 167Ā°F)
- Max Temperature: 105Ā°C (221Ā°F)
- Insertion Force: ā¤90 N
- Withdrawal Force: ā„310 N
More Information
MFRPartNum:
MC4-3-1-KIT
