Tycon Power Systems

Part:
TPSHP-12-70

Tycon Power Systems TPSHP-12-70 70W 12V Solar Panel - 30 x 25

$279.99
Condition:
New

PRODUCT SPECIFICATIONS

The TPSHP series solar panels are high efficiency designs with excellent low light performance. The multicrystalline silicon solar cells are laminated with a TPT (Tedlar/Polyester/Tedlar) and EVA (Ethylene Vinyl Acetate) bi-layer for high reliability and long life. The cell array is sealed in a heavy duty extruded aluminum frame with a high transparency low iron tempered glass cover to protect the solar cells from harsh environments; hail, wind, snow and ice. The solar panels are easy to mount because of the aluminum frame design. The wired connections are via a weatherproof junction box on the back of the panels. The Normal Operating Cell Temperature is specified at 47°C.

  • Features
    • Outstanding Low Light Performance.
    • Solar cells laminated with TPT/EVA bi-layer for long life. 25 year solar cell output warranty.
    • High Efficiency with high transparency low iron tempered glass cover.
    • Rugged extruded anodized aluminum frame.
    • Sealed for protection from harsh environments.
    • Enclosed junction box for wired connections.
  • Applications
    • Battery Charging Applications
    • Surveillance Cameras
    • Wireless Base Stations
    • Outdoor Lighting
    • On-Grid or Off-Grid systems
    • Backup Power Systems

Dimensions

  • 774 x 675 x 30mm (30.5 x 26.6 x 1.2”)

Weight

  • 6kg (13.2lb)

Technical Description

  • Maximum Power (+/-5%): 70W
  • Voltage at Pmax (Vmp): 17.2V
  • Current at Pmax (Imp): 4.07A
  • Open Circuit Voltage (Voc): 21.6V
  • Short Circuit Current (Isc): 4.35A
  • Short Circuit I Temp Coeff: .065% / °C
  • Open Circuit V Temp Coeff: -80mV / °C
  • Output Power Temp Coeff: 0.5%/°C
  • Continuous Power Capability (6hrs average sunlight per day): 17W

More Information

MFRPartNum:
TPSHP-12-70
Datasheet:
