PRODUCT SPECIFICATIONS
The EdgeRouter™ X SFP combines cost-effective routing performance with the convenience of passive PoE support in a compact form factor.
Compact but powerful router sporting (5) Gigabit RJ45 ports with passive PoE support and an SFP port.
Features
- (5) GbE RJ45 ports with 24V passive PoE
- (1) SFP port
- 50W total PoE availability
Dimensions
- 142 x 75 x 23 mm (5.59 x 2.95 x 0.91")
Weight
- 215 g (7.58 oz)
Technical Description
- Hardware
- Processor: Dual-Core 880 MHz, MIPS1004Kc
- Memory: 256 MB DDR3 RAM
- Code Storage: 256 MB NAND
- Max. Power Consumption: 5W
- Power Input: 24VDC, 2.5A Power Adapter (Included)
- Power Supply: External AC/DC Adapter
- Supported Voltage Range: 9 to 26VDC
- Buttons: Reset
- LEDs: Power, Link/Activity (6), PoE (5)
- Wall Mount: Yes
- Operating Temperature: -10 to 45° C (14 to 113° F)
- Operating Humidity: 10 to 90% Noncondensing
- Certifications: CE, FCC, IC
- Networking Interfaces
- Data/PoE Input Port: (5) 10/100/1000 RJ45 Ports
- Data Port: (1) 100/1000 SFP Port
- PoE with 24VDC Power Adapter
- PoE Out Voltage Range: 22-24VDC
- Max. PoE Wattage Per Data Port: 12W (24V)
- Max. PoE Wattage Combined for All 5 Data Ports: 50W
- PoE Method: Passive
More Information
MFRPartNum:
ER-X-SFP
Datasheet:
