PRODUCT SPECIFICATIONS
5 GHz PtMP LTU Client, functions in a PtMP environment with the LTU-Rocket as the BaseStation.
Incorporating Ubiquiti’s proprietary LTU technology, the LTU-Lite is a 5 GHz radio with an integrated antenna design for use as a PtMP CPE. LTU technology breaks through the limitations of 802.11 WiFi technology and supports 1024 QAM for superior performance. Channel width flexibility allows independent TX and RX channel frequency configurations anywhere within the radio band to avoid local interference.
Features:
- High data and performance rate (1024 QAM)
- 10/20/30/40/50/60/80/100 MHz* channel bandwidth
- Central configuration management from AP side
- Frequency split
- Auto power adjustments
- Router mode support
Functions in a PtMP environment with the LTU-Rocket as the basestation.
Mechanical
- Dimensions: 153 x 84 x 39.5 mm (6.02 x 3.31 x 1.56")
- Weight: 250 g (8.82 oz)
- Enclosure material: UV-stabilized polycarbonate
- Mounting: Pole mount, wall mount (Kit included)
- Wind survivability: 200 km/h (125 mph)
- Wind loading: 20 N at 200 km/h (4.5 lbf at 125 mph)
Hardware
- Networking interface: (1) 10/100/1000 MbE RJ45 port
- Power method: 24V passive PoE (Pairs 4, 5+; 7, 8-)
- Power supply: 24V, 0.5A Gigabit PoE adapter (Included)
- Supported voltage range: 22—26V
- Max. power consumption: 8.5W
- ESD/EMP protection: Air/contact: ± 24kV
- Operating temperature: -40 to 60° C (-40 to 140° F)
- Operating humidity: 5 to 95% noncondensing
- Certifications: CE, FCC, IC
Software
- OS: airOS®
- Modes: PtMP CPE only
- Management interface:
- Bluetooth management for easy setup over UISP App
- WEB UI
- Minimum software requirements: Any modern web browser/iOS™ or Android™ based smartphone
Product Includes
- LTU-Lite-US
- Wall Mount Bracket
- Screws
- Screw Anchors
- Zip Tie
- Gigabit PoE (24v, 0.5A) with Mounting Bracket
- Power Cord
More Information
MFRPartNum:
LTU-Lite-US
