PRODUCT SPECIFICATIONS
Ubiquiti UACC-CWDM-8 CWDM Mux Demux 8
Rack-mountable 8-channel 1450 to 1590 nm CWDM mux demux designed to increase capacity of existing fiber infrastructure.
Key Features:
- (8) 1450 to1590 nm channel ports
- (1) Duplex LC UPC communication port for linking to another CWDM Mux Demux 8 with a pair of single-mode fiber cables
- (1) Duplex LC UPC monitor port for seamless observation with a power meter or optical spectrum analyzer
- (1) Duplex LC UPC expansion port for linking to CWDM Mux Demux 4 to add more channels
- Compatibility: USW-Aggregation, USW-Pro-Aggregation
Technical Description:
- Mechanical:
- Dimensions: 442 x 120 x 43.7 mm ( 17.4 x 4.7 x 1.7')
- Weight: 1.4 kg (3.2 lb)
- Enclosure material: Metal
- Hardware:
- Connector type:
- (1) COM (LC/UPC)
- (1) MON (LC/UPC)
- (1) EXP (LC/UPC)
- (1) 1450 to 1590 nm (LC/UPC)
- Pigtail and connector type:
- COM: 0.9 mm black LC/UPC
- Other ports: 0.9 mm white LC/UPC
- Fiber type: SMF-28e
- Fiber length: ≥0.5 to 1 m
- Channel count: 8 CH Mux/Demux
- Channel center wavelength: 1450/1470/1490/1510/1530/1550/1570/1590 nm
- Min. channel passband: ±6.5 nm
- Max. insertion loss: <2.5 dB
- Isolation:
- Adjacent channel: Max. 30 dB
- Non-Adjacent channel: Min. 40 dB
- Max. passband ripple: 0.3 dB
- Max. Polarization Dependent Loss: 0.1 dB
- Min. directivity: 55 dB
- Min. return loss: 50 dB
- Max. polarization mode dispersion: 0.1 ps
- Max. power handling: 500 mW
- Storage temperature: -40 to 90° C (-40 to 194° F)
- Ambient operating temperature: -30 to 75° C (-22 to 167° F)
- Connector type:
More Information
MFRPartNum:
UACC-CWDM-8
