PRODUCT SPECIFICATIONS
Ubiquiti UACC-ETH-SP-Pro Ethernet Surge Protection Outdoor
ESD protection for outdoor high-speed networks.
Key Features
- Protects outdoor Ethernet devices, up to 20kA discharge current.
- (2) Passive, surge-protected RJ45 connections
- Quick and easy installation
- Compatible with 10 GbE networks
- Mechanical:
- Dimensions: 91 x 61 x 32.5 mm (3.6 x 2.4 x 1.3')
- Weight: 95 g (3.35 oz)
- Enclosure Material: Polycarbonate
- Weatherproofing: IPX5
- Hardware:
- Networking Interface: (2) RJ45 female connectors
- DC Spark-Over Voltage: 90V @ 100V/s
- Max. Impulse Spark-Over Voltage: 600V @ 1kV/µs
- Discharge Current: 20kA
- Insulation: Max. Resistance: 1G ohm @ 50V
- Max. Capacitance: 1.0 pF @ 1 MHz
- Data Line Protection: Up to 10 Gbps
- PoE Support: ✓
- ESD/EMP Protection: Absorbing transient current with response to surge voltage from 100V/s to 1kV/µs
- Ambient Operating Temperature: -30 to 65° C (-22 to 149° F)
- Ambient Operating Humidity: 10 to 90% noncondensing
- Shock and Vibration Certification: ETSI300-019-1.4 Standard
More Information
MFRPartNum:
UACC-ETH-SP-Pro
