Ubiquiti

Part:
UACC-PSU-12V-150W

Ubiquiti UACC-PSU-12V-150W 150W Hot-Swappable 12V Power Supply Module for EFG and UXG-Enterprise

$119.00
Condition:
New
Notice:
Online Reseller Restriction

PRODUCT SPECIFICATIONS

Ubiquiti UACC-PSU-12V-150W 150W Hot-Swappable Power Module

The Ubiquiti UACC-PSU-12V-150W is a replacement AC-to-DC power supply module for the Enterprise Fortress Gateway (EFG) and Gateway Enterprise (UXG-Enterprise). It delivers 150W of output power at 12V DC and 12.5A.

Designed for the supported gateways' hot-swappable power supply bays, this module is useful for replacing a failed PSU or keeping a spare available for maintenance. Its 100–240V AC, 50/60 Hz input supports installations using either 120V or 230V mains power.

Key Features

  • Exact replacement model: UACC-PSU-12V-150W.
  • 150W total output capacity with 12V DC, 12.5A output.
  • Hot-swappable design for supported Ubiquiti gateways.
  • 100–240V AC input at 50/60 Hz.
  • Overvoltage and overcurrent protection.
  • SGCC steel enclosure.

Power and Replacement Use

This module supplies power through the compatible gateway's dedicated PSU interface. The 150W rating describes the module's output capacity; actual power consumption depends on the connected equipment and operating conditions.

When replacing a module in an operating redundant-power configuration, follow Ubiquiti's installation procedure and ensure the remaining power supply is connected and functioning.

Compatibility

Ubiquiti identifies the EFG and UXG-Enterprise as supported devices. Match the exact replacement PSU model before ordering; voltage or wattage alone does not establish compatibility with other equipment.

Ideal Applications

  • Replacing a failed EFG or UXG-Enterprise power supply module.
  • Maintaining spare PSUs for supported UniFi gateway installations.
  • Servicing supported gateways with redundant hot-swappable power supplies.

Compatible Products

The UACC-PSU-12V-150W is designed for the dedicated hot-swappable power supply bays in the following Ubiquiti gateways:

Important: This module uses a proprietary PSU interface. It is not a universal 12V adapter or a PoE injector. Do not assume compatibility with other UniFi devices, third-party CRPS equipment, or other power modules based only on appearance, voltage, or wattage.

Replacement guidance: Follow the installation instructions for the exact gateway and PSU. Continued operation during replacement requires a functioning, powered redundant PSU.

Technical Specifications

General

  • Brand: Ubiquiti
  • Model / MPN: UACC-PSU-12V-150W
  • Product Type: Hot-swappable AC-to-DC power supply module
  • Supported Devices: EFG and UXG-Enterprise
  • PSU Interface: Proprietary

Electrical

  • Input Voltage Range: 100–240V AC
  • Input Frequency: 50/60 Hz
  • Maximum Input Current: 7A at 120V AC; 3.6A at 230V AC
  • Output Voltage: 12V DC
  • Rated Output Current: 12.5A
  • Total Output Power: 150W
  • Inrush Current: Less than 50A peak
  • Full-Load Efficiency: Greater than 81%

Protection

  • Overvoltage Protection: 13.5V
  • Overcurrent Protection: 18.5–22.5A

Physical Specifications

  • Dimensions: 185 x 73.5 x 40 mm (7.3 x 2.9 x 1.6 inches)
  • Weight: 733 g (1.6 lb)
  • Enclosure Material: SGCC steel

Environmental

  • Ambient Operating Temperature: -5 to 50°C (23 to 122°F)
  • Ambient Operating Humidity: 5–95%, noncondensing

Certifications

  • Listed Certifications: CE, FCC, IC, UKCA, KC, CCC, RoHS

View Ubiquiti UACC-PSU-12V-150W Technical Specifications

 View Ubiquiti UACC-PSU-12V-150W Installation Guide
