PRODUCT SPECIFICATIONS
Ubiquiti UDB Device Bridge
Plug-and-play, wireless bridging PoE adapter with integrated UniFi WiFi Auto-Link.
Key Features
- (1) GbE LAN port that provides up to 15W of PoE
- 5 GHz band with up to 867 Mbps throughput rate
- Compatible with UniFi Protect PoE cameras, Talk phones, and various IoT devices via an Ethernet connection
- Note: UniFi Consoles and APs must have the latest software updates installed.
Techinical Specification
- Mechanical
- Dimensions: 130 x 55 x 34 mm (5.1 x 2.2 x 1.3')
- Weight: 200 g (7.1 oz)
- Enclosure material: Polycarbonate
- Mount materia: Polycarbonate
- Hardware
- Management interface: WiFi
- Networking interface: (1) GbE RJ45 port
- PoE interface: (1) Passive PoE output
- Button: (1) Factory-reset
- LED:
- (4) Blue: signal
- (1) White/blue: indicator
- Power method: 100—240V AC, 0.45A Max., 50/60 Hz
- Max. power consumption: AC input: 25W
- Excluding PoE output: 10W
- Max. PoE wattage per port: 15W
- Supported voltage range: 100—240V AC
- WiFi standards: 802.11a/n/ac
- Max. TX power: 21 dBm
- MIMO: 2 x 2
- Max. data rate: 866.7 Mbps (BW80)
- Antenna gain: Internal antenna 5 dBi / External omni antenna : 4 dBi
- Antenna: (1) Internal antenna (1) RP-SMA connector for external omni-antenna
- Supported Data Rates:
- 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
- 802.11ac: 6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
More Information
MFRPartNum:
UDB
