PRODUCT SPECIFICATIONS
Ubiquiti UDM-Beast Dream Machine Beast
The Ubiquiti UDM-Beast Dream Machine Beast is a hyperscale-class cloud gateway built for large UniFi deployments that need high security throughput, high client capacity, and broad application support in one 1U rackmount system. Ubiquiti rates it for 25 Gbps IDS/IPS throughput, 7,500+ simultaneous users, and support for the full UniFi application suite, including Network, Protect, Access, Talk, and Connect.
The UDM-Beast also supports up to 8 WAN ports, dual NVR drive bays, integrated 128 GB SSD storage, and gateway redundancy features including Shadow Mode (VRRP) and DC power backup. Its mixed copper and fiber port layout makes it suitable for high-speed uplinks, multi-WAN designs, and large-scale UniFi edge deployments.
Large-Scale UniFi Gateway Performance
Ubiquiti positions the UDM-Beast for large-scale environments that need deep security inspection, high connection capacity, and centralized control across multiple UniFi applications. Official specs list support for 750+ managed UniFi devices, 200 managed access hubs, and up to (100) HD, (60) 2K, or (40) 4K managed cameras.
Integrated Routing, Security, and Availability
The UDM-Beast combines advanced gateway and security functions in one platform, including a stateful firewall, application-aware Layer 7 firewall, DPI and traffic identification, content filtering, intrusion prevention, and license-free SD-WAN. It also supports multi-WAN load balancing, dynamic routing with OSPF and BGP, VPN services, and Shadow Mode high availability.
Key Features
- Hyperscale-class UniFi cloud gateway for large-scale deployments
- 25 Gbps IDS/IPS throughput
- 7,500+ simultaneous user capacity
- Supports the UniFi application suite: Network, Protect, Access, Talk, and Connect
- Up to 8 WAN ports with default WAN ports of (1) 25G SFP28 and (1) 10 GbE RJ45
- Mixed copper and fiber port layout with 10 GbE RJ45, 10G SFP+, and 25G SFP28 connectivity
- Shadow Mode (VRRP) gateway failover and DC power backup support
- Dual 3.5" NVR HDD bays plus built-in 128 GB SSD storage
Applications
- Large UniFi gateway deployments requiring high client capacity and deep security inspection
- Rack-mounted multi-WAN edge deployments using copper and fiber uplinks
- UniFi environments running Network, Protect, Access, Talk, and Connect from one platform
- Sites that need gateway high availability with Shadow Mode (VRRP) failover
- Deployments managing large counts of UniFi devices, cameras, and access hubs
Technical Specifications
- Capacity
- Managed UniFi Devices: 750+
- Managed Cameras: (100) HD (60) 2K (40) 4K
- Managed Access Hubs: 200
- Simultaneous Users Connected: 7,500+
- IDS/IPS Throughput: 25 Gbps
- Ports / Interfaces
- Max. WAN Port Count: 8
- Default WAN Ports: (1) 25G SFP28 (1) 10 GbE RJ45
- 1 GbE RJ45: 2 (1G/100M/10M)
- 10 GbE RJ45: 8 (10G/5G/2.5G/1G/100M)
- 10G SFP+: 2 (10G/1G)
- 25G SFP28: 2 (25G/10G/1G)
- Console: 1
- Security
- Stateful Firewall: ✓
- Application-Aware Layer 7 Firewall: ✓
- DPI & Traffic Identification: ✓
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps): ✓
- Content Filtering: ✓
- Intrusion Prevention (IPS/IDS): ✓
- Ad Blocking: ✓
- IDS/IPS Signatures: 55,000+ with CyberSecure
- ESD/EMP Protection: Air: ± 8kV, contact: ± 4kV
- VPN & SD-WAN
- License-Free SD-WAN: ✓
- Site Magic: ✓
- IPsec: ✓
- OpenVPN: ✓
- Identity Endpoint One-Click VPN: ✓
- Teleport Zero-Configuration VPN: ✓
- WireGuard: ✓
- L2TP: ✓
- VPN Client OpenVPN: ✓
- VPN Client WireGuard: ✓
- Networking
- Multi-WAN Load Balancing: ✓
- Shadow Mode (VRRP) High Availability: ✓
- LACP Port Aggregation: ✓
- OSPF: ✓
- BGP: ✓
- Advanced QoS: ✓
- Multicast DNS (mDNS): ✓
- Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT): ✓
- Integrated RADIUS Server: ✓
- RADIUS over TLS (RadSec): ✓
- Additional Internet Failover with UniFi LTE Backup: ✓
- Internet Quality and Outage Reporting: ✓
- MAC Address Table Size: 32,000
- Policy-based WAN and VPN Routing: ✓
- Customizable DHCP Server: ✓
- IPv6 ISP Support: ✓
- IGMP Proxy: ✓
- All Traffic Flows: ✓
- Hardware
- NVR Storage: (2) 3.5" NVR HDD bays Built-in 128 GB SSD for Faster Experience
- Processor: Octa-core ARM® v9 at 2.1 GHz
- System Memory: 16 GB
- On-board Storage: Integrated 128 GB SSD
- LCM Display: 1.3" touchscreen
- Management: Ethernet Bluetooth
- LEDs: Ethernet, SFP+, SFP28, RPS, HDD
- Button: (1) Factory reset
- Redundancy: Shadow Mode (VRRP) Gateway Failover DC Power Backup
- Power
- Max. Power Consumption: 100W
- Power Method: (1) Universal AC input, 100–240V AC, 3A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 13.05A
- Power Supply: AC/DC, internal, 150W
- Supported Voltage Range: 100–240V AC
- Heat Dissipation: 342 BTU/hr
- Physical
- Dimensions: 442.4 x 43.7 x 325 mm (17.4 x 1.7 x 12.8")
- Form Factor: Rack mount (1U)
- Weight: 5.5 kg (12.13 lb)
- Enclosure Material: Aluminium CNC, SGCC steel
- Mount Material: SGCC steel
- Environmental
- Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
- Ambient Operating Humidity: 5 to 95% noncondensing
- Software
- UniFi Application Suite: Network, Protect, Access, Talk, Connect
- Mobile App: UniFi iOS™: Version 10.34.0 and later UniFi Android™: Version 10.37.1 and later
