PRODUCT SPECIFICATIONS
Ubiquiti UDR-5G-Max - Dream Router 5G Max
The Ubiquiti UDR-5G-Max is a desktop UniFi Cloud Gateway with 5G up to 3.4 Gbps, integrated WiFi 7, a 10G SFP+ port, and a 4-port 2.5 GbE switch with one PoE port. It supports 300+ simultaneous users connected, 30+ managed UniFi devices, and NVR storage through a pre-installed 64 GB microSD card.
The unit is built for UniFi network deployments that need wired routing, integrated wireless coverage, cellular connectivity, security inspection, and local camera storage in one desktop gateway. It is certified with AT&T and T-Mobile; T-Mobile Home Internet SIMs are not supported and a data-only plan is required.
Key Features
- Desktop UniFi Cloud Gateway with integrated 5G, WiFi 7, 10G SFP+, and 2.5 GbE switching
- 5G NSA peak data speed up to Downlink 3.4 Gbps Uplink 560 Mbps
- Integrated WiFi with 160 m² (1,750 ft²) coverage area
- Supports 300+ simultaneous users connected and 30+ managed UniFi devices
- Default WAN ports include (1) 10G SFP+ and (1) 2.5 GbE RJ45
- 4-port 2.5 GbE RJ45 switch with (1) PoE port and 15.4W PoE budget
- IDS/IPS throughput of 2.3 Gbps
- Pre-installed 64 GB microSD for NVR storage
Applications
- Small business networks that need routing, wireless coverage, and cellular connectivity in one desktop gateway
- Managed network deployments with local user, device, and camera capacity
- Sites that need internet failover, VPN access, firewall filtering, and traffic inspection
- Retail, office, or branch locations using local NVR storage for supported cameras
Technical Specifications
- Capacity
- Managed UniFi Devices: 30+
- Managed Cameras: (5) HD (2) 2K (1) 4K
- Simultaneous Users Connected: 300+
- IDS/IPS Throughput: 2.3 Gbps
- Coverage Area: 160 m² (1,750 ft²)
- Ports / Interfaces
- Max. WAN Port Count: 4
- Default WAN Ports: (1) 10G SFP+ (1) 2.5 GbE RJ45
- Port Layout, 2.5 GbE RJ45: 4 (1 PoE) (2.5G/1G/100M)
- Port Layout, 10G SFP+: 1 (10G/1G)
- Expansion Slot: MicroSD Card
- SIM: (2) Nano SIM (1) Nano-SIM or eSIM
- Management: Ethernet Bluetooth
- Button: (1) Factory reset
- Wireless
- WiFi Standard: 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
- Throughput, 6 GHz: 5.7 Gbps
- Throughput, 5 GHz: 4.3 Gbps
- Throughput, 2.4 GHz: 688 Mbps
- MIMO, 6 GHz: 2 x 2 (DL/UL MU-MIMO)
- MIMO, 5 GHz: 2 x 2 (DL/UL MU-MIMO)
- MIMO, 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
- Antenna Gain, 6 GHz: 8 dBi
- Antenna Gain, 5 GHz: 5 dBi
- Antenna Gain, 2.4 GHz: 4 dBi
- Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
- Max. BSSIDs: 4 per Radio
- Networking
- Multi-WAN Load Balancing: Yes
- Dynamic Routing, OSPF: Yes
- Advanced QoS: Yes
- Multicast DNS (mDNS): Yes
- Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT): Yes
- Integrated RADIUS Server: Yes
- RADIUS over TLS (RadSec): Yes
- Additional Internet Failover with UniFi LTE Backup: Yes
- Internet Quality and Outage Reporting: Yes
- MAC Address Table Size: 2,000
- Security
- Stateful Firewall: Yes
- Application-Aware Layer 7 Firewall: Yes
- DPI & Traffic Identification: Yes
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps): Yes
- Content Filtering: Yes
- Intrusion Prevention (IPS/IDS): Yes
- Ad Blocking: Yes
- IDS/IPS Signatures: 20,000+ with CyberSecure
- ESD/EMP Protection: Air: ± 8kV, contact: ± 4kV
- VPN & SD-WAN
- License-Free SD-WAN: Yes
- Site-to-Site VPN, Site Magic: Yes
- Site-to-Site VPN, IPsec: Yes
- Site-to-Site VPN, OpenVPN: Yes
- VPN Server, Identity Endpoint One-Click VPN: Yes
- VPN Server, Teleport Zero-Configuration VPN: Yes
- VPN Server, WireGuard: Yes
- VPN Server, OpenVPN: Yes
- VPN Server, L2TP: Yes
- VPN Client, OpenVPN: Yes
- VPN Client, WireGuard: Yes
- Site-to-Site VPN Single Tunnel Throughput, Site Magic: 20
- VPN Client Single Tunnel Throughput, WireGuard: 8
- VPN Client Single Tunnel Throughput, OpenVPN: 8
- Hardware
- Form Factor: Desktop
- NVR Storage: Pre-installed 64 GB microSD for NVR
- Processor: Quad-core ARM® Cortex®-A53 at 1.5 GHz
- System Memory: 3 GB
- Enclosure Material: Polycarbonate
- LCM Display: 4.7' touchscreen
- Power
- PoE Budget: 15.4W
- Max. PoE Wattage per Port by PSE, PoE: 15.4W
- Voltage Range PoE Mode: 44-57V
- Max. Power Consumption: 34.5W (Excluding PoE output)
- Power Method: DC jack (54V DC/1.1A)
- Power Supply: 54V DC/1.1A (Adapter included)
- Supported Voltage Range: 100-240V AC
- Heat Dissipation: 115 BTU/hr (Excluding PoE output)
- Physical
- Dimensions: 110 x 110 x 250 mm (4.3 x 4.3 x 9.8')
- Weight: 1.4 kg (3.1 lb)
- Environmental
- Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
- Ambient Operating Humidity: 5 to 95% noncondensing
- Software
- UniFi Application Suite: Network, Protect, Access, Talk, Connect
- Mobile App: UniFi iOS™: Version 10.33.0 and later UniFi Android™: Version 10.36.1 and later
- Certifications
- NDAA Compliant: Yes
- Certifications: FCC, IC, CE, GCF, PTCRB, AT&T, T-Mobile, Wi-Fi Alliance®
More Information
MFRPartNum:
UDR-5G-Max-US
