PRODUCT SPECIFICATIONS
Ubiquiti UDR7 Dream Router 7
Desktop 10G Cloud Gateway with integrated WiFi 7, PoE switch, microSD storage, and full UniFi application support.
Key Features:
- Buit-in tri-radio 2.4/ 5 / 6 GHz WiFi 7
- LCM display
- Status LED light
- 300+ client capacity
- (3) 2.5 GbE RJ45 WAN port
- microSD expansion slot*
- Note: 64 GB pre-installed microSD
Technical Specification:
- Overview:
- Dimensions: Ø110 x 184.1 mm (Ø4.3 x 7.3')
- UniFi Application Suite:
- Network
- Protect
- Access
- Talk
- Connect
- Managed UniFi Devices: 30+
- Managed Cameras:
- (5) HD
- (2) 2K
- (1) 4K
- Simultaneous Users Connected: 300+
- Default WAN Ports:
- (1) 10G SFP+
- (1) 2.5 GbE RJ45
- LAN Ports: (3) 2.5 GbE RJ45 including (1) PoE
- IDS/IPS Throughput: 2.3 Gbps
- Form Factor: Compact desktop
- Security:
- Stateful Firewall
- Application-Aware Layer 7 Firewall
- DPI & Traffic Identification
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
- Content Filtering
- Intrusion Prevention (IPS/IDS)
- Ad Blocking
- IDS/IPS Signatures: 20,000+ with CyberSecure
- VLAN/Subnet-based Traffic Segmentation
- VPN & SD-WAN:
- License-Free SD-WAN
- Site-to-Site VPN:
- Site Magic
- IPsec
- OpenVPN
- VPN Server:
- Identity Endpoint One-Click VPN
- Teleport Zero-Configuration VPN
- WireGuard
- OpenVPN
- L2TP
- VPN Client:
- OpenVPN
- WireGuard
- Networking:
- Multi-WAN Load Balancing
- Dynamic Routing
- OSPF
- Advanced QoS
- Multicast DNS (mDNS)
- Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
- Integrated RADIUS Server
- RADIUS over TLS (RadSec)
- Additional Internet Failover with UniFi LTE Backup
- Internet Quality and Outage Reporting
- MAC Address Table Size: 2,000
- Policy-based WAN and VPN Routing
- Customizable DHCP Server
- IPv6 ISP Support
- IGMP Proxy
- Integrated WiFi:
- WiFi Standard: 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
- Throughput:
- 6 GHz: 5.7 Gbps
- 5 GHz: 4.3 Gbps
- 2.4 GHz: 688 Mbps
- MIMO:
- 6 GHz: 2 x 2 (DL/UL MU-MIMO)
- 5 GHz: 2 x 2 (DL/UL MU-MIMO)
- 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
- Antenna Gain:
- 6 GHz: 6 dBi
- 5 GHz: 7 dBi
- 2.4 GHz: 5 dBi
- Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
- Max. BSSIDs: 4 per Radio
- Supported Data Rates:
- 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11b: 1, 2, 5.5, 11 Mbps
- 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n: 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
- 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
- 802.11ax (WiFi 6/6E): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
- 802.11be (WiFi 7): 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
- Hardware:
- NVR Storage: Pre-installed 64GB microSD for NVR
- Expansion Slot: MicroSD Card
- PoE Budget: 15.4W
- Max. PoE Wattage per Port by PSE:
- PoE: 15.4W
- Voltage Range PoE Mode: 44-57V
- Max. Power Consumption: 26W (Excluding PoE output)
- Power Method: Universal AC input, 100-240VAC, 1.5A Max, 50/60 Hz
- Power Supply: AC/DC, Internal, 50W
- Max. TX Power:
- 6 GHz: 24 dBm
- 5 GHz: 26 dBm
- 2.4 GHz: 23 dBm
- Supported Voltage Range: 100-240V AC
- Processor: Quad-core ARM® Cortex®-A53 at 1.5 GHz
- System Memory: 3 GB
- Weight: 1.1 kg (2.4 lb)
- Enclosure Material: Polycarbonate
- LCM Display: 0.96' status display
- Management:
- Ethernet
- Bluetooth
- LEDs: System
- ESD/EMP Protection:
- Air: ± 8kV
- Contact: ± 4kV
- Ambient Operating Temperature: -10 to 40° C (14 to 104° F)
- Ambient Operating Humidity: 5 to 95% noncondensing
- Certifications: CE, FCC, IC
- Button: (1) Factory-reset
- Software:
- VLAN: 802.1Q
- Guest Traffic Isolation
- Application Requirements:
- UniFi Network Version 9.0.108 and later
