PRODUCT SPECIFICATIONS
Ubiquiti UCG-Fiber Cloud Gateway Fiber
Desktop 10G Cloud Gateway with integrated PoE switch, selectable NVR storage, and full UniFi application support.
Key Features:
- Full UniFi application support
- 500+ client capacity
- 0.96* information display
- (4) 2.3 GbE RJ45 ports with one PoE+
- 10G SFP+ port
- Reset button
- 10 GbE RJ45 WAN port
- 10G SFP+ WAN port
- Power input*
- Note: 54V DC 1.1A AC power adapter included
Technical Specification:
- Overview:
- Dimensions: 212.8 x 127.6 x 30 mm (8.3 x 5 x 0.5 ')
- UniFi Application Suite:
- Network
- Protect
- Access
- Talk
- Connect
- Managed UniFi Devices: 50+
- Managed Cameras:
- (15) HD
- (8) 2K
- (5) 4K
- Simultaneous Users Connected: 500+
- Default WAN Ports:
- (1) 10G SFP+
- (1) 10 GbE RJ45
- LAN Ports:
- (1) 10G SFP+
- (4) 2.5 GbE RJ45
- IDS/IPS Throughput: 5 Gbps
- Form Factor: Compact desktop
- Security:
- Stateful Firewall
- Application-Aware Layer 7 Firewall
- DPI & Traffic Identification
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
- Content Filtering
- Intrusion Prevention (IPS/IDS)
- Ad Blocking
- IDS/IPS Signatures: 55,000+ with CyberSecure
- VPN & SD-WAN:
- License-Free SD-WAN
- Site-to-Site VPN:
- Site Magic
- IPsec
- OpenVPN
- VPN Server:
- Identity Endpoint One-Click VPN
- Teleport Zero-Configuration VPN
- WireGuard
- OpenVPN
- L2TP
- VPN Client:
- OpenVPN
- WireGuard
- Site-to-Site VPN Single Tunnel Throughput:
- Site Magic: 20
- VPN Client Single Tunnel Throughput:
- WireGuard: 8
- OpenVPN: 8
- Networking:
- Multi-WAN Load Balancing
- Dynamic Routing:
- OSPF
- Advanced QoS
- Multicast DNS (mDNS)
- Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
- Integrated RADIUS Server
- RADIUS over TLS (RadSec)
- Additional Internet Failover with UniFi LTE Backup
- Internet Quality and Outage Reporting
- MAC Address Table Size: 4,000
- Hardware:
- NVR Storage: Selectable NVMe SSD up to 2 TB
- PoE Budget: 30W
- Max. PoE Wattage per Port by PSE:
- PoE+: 30W
- Voltage Range PoE Mode: 50-57V
- Max. Power Consumption: 29.4W (Excluding PoE output)
- Power Method: DC jack (54V DC/1.1A)
- Power Supply: 54V DC/1.1A (adapter included)
- Supported Voltage Range: 100-240V AC
- Processor: Quad-core ARM® Cortex®-A73 at 2.2 GHz
- System Memory: 3 GB
- Weight:
- Without SSD: 675 g (1.5 lb)
- With SSD: 734 g (1.6 lb)
- Enclosure Material: Polycarbonate
- LCM Display: 0.96' status display
- Management:
- Ethernet
- Bluetooth
- LEDs:
- Ethernet
- SFP+
- ESD/EMP Protection:
- Air: ± 8kV
- Contact: ± 4kV
- Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
- Ambient Operating Humidity: 5 to 95% noncondensing
- Certifications: CE, FCC, IC
- Button: (1) Factory-reset
More Information
MFRPartNum:
UCG-Fiber
