PRODUCT SPECIFICATIONS
Ubiquiti UF-LOCO Fiber Loco
GPON customer-premises equipment (CPE) that pairs high performance with extremely low power consumption.
Key Features:
- GPON CPE with integrated WiFi
- 2.4 Gbps uplink 1.1 Gbps downlink up to 20 km
- Wall mount
- GPON port
- Micro-USB power input*
- Reset Button
- GbE RJ45 LAN port and 24V PoE in
- *Micro-USB 5V 1A power adapter included in single pack only
Technical Specification:
- Mechanical:
- Dimensions: 76.5 x 76.5 x 26.4 mm (3 x 3 x 1')
- Weight: 77 g (2.7 oz)
- Enclosure material: Polycarbonate
- Hardware:
- Networking interface:
- (1) SC/APC, ITU-G.984 GPON WAN port
- (1) GbE RJ45 LAN ports
- Management interface:
- Ethernet In-Band
- PON
- Power method:
- Micro-USB: 5V, 1A
- 24V Passive PoE (Pins +4, 5; -7, 8)
- Power supply: Micro-USB Power Adapter*
- *Included only in the single-pack of the UF-LOCO.
- Supported voltage range: 4.7–5.3V
- Max. power consumption: 3.5W
- Total non-blocking line rate:
- Downstream: 2.488 Gbps
- Upstream: 1.244 Gbps
- Normal range of optical module:
- TX: 1.5 to 5 dBm
- RX: -8 to -28 dBm
- Button: (1) Factory reset
- Ambient operating temperature: -10 to 45° C (14 to 113° F)
- Ambient operating humidity: 10 to 90% noncondensing
- Certifications: CE, FCC, IC
- Networking interface:
- LEDs:
- PON status:
- (3) signal LEDs
- All-OFF: bootup
- 1x red: signal too low (< -28 db)
- 1x white: signal low (>= -28 db)
- 2x white: signal good (>= -25 db)
- 3x white: signal strong (>= -11 db)
- 1x red + 2x white: signal too strong (>= -8 db)
- 3x red: no signal
- LEDs alternate between red and a signal strength indicator: No authority
- Ethernet:
- Steady white: link up
- Blinking white: activity
- OFF: link down
- Power:
- White: ON
- PON status:
- Software:
- Mode: ONU/ONT layer 2/3 Ethernet switch
- Services: Web server, telnet, NAT, bridging and routing, firewall features, and application passthrough features
- Utilities: Dashboard, monitoring, alarms, and logs
- Other: Remote reset, remote reboot, remote firmware upgrade, VLAN support
- Security: GEM Port Encryption
- Ubiquiti specific features: UISP Mobile App
- Fiber:
- Operating wavelength:
- TX: 1310 nm
- RX: 1490 nm
- Line code: Scrambled NRZ
- Optical interface nominal bit rate:
- Downstream: 2488.32 Mbit/s
- Upstream: 1244.16 Mbit/s
- Physical reach: 20 km
- Operating wavelength:
