PRODUCT SPECIFICATIONS
Eight-port, Layer 2, Gigabit PoE switch designed for MicroPoP applications and building secure, high-performance networks.
Features:
- (8) GbE RJ45 ports with 27V passive PoE output
- (1) SFP port
- 110W (27V) total PoE availability*, 15W/port (2-pair) / 30W/port (4-pair)
- Port isolation, speed limiting, and DHCP snooping functionality
- Easy Bluetooth setup with the UISP Mobile app
*When powered with the included AC/DC adapter.
Can be staged outdoors when enclosed in the UISP Box (sold separately).
Technical Description
- Mechanical
- Dimensions: 210.4 x 95 x 29 mm (8.3 x 3.7 x 1.1")
- Weight: 610 g (1.3 lb)
- Enclosure material: Polycarbonate
- Hardware
- Total non-blocking throughput: 9 Gbps
- Switching capacity: 18 Gbps
- Forwarding rate: 13.392 Mpps
- Networking interface:
- (8) GbE RJ45 ports
- (1) 1G SFP port
- Management interface:
- Ethernet In-band
- Bluetooth BLE
- Power method: External AC/DC adapter
- Power supply: 27V DC, 4.4A power adapter (included)
- Supported voltage range: 24-28V DC
- Max. power consumption: 8W (Excluding PoE output)
- ESD/EMP protection: Air: ± 15kV, contact: ± 8kV
- Operating temperature: -10 to 50° C (14 to 122° F)
- Operating humidity: 5 to 95% non-condensing
- Certifications: CE, FCC, IC
- PoE
- PoE interface: (8) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-)
- Total available PoE: 110W
- Max. passive PoE wattage per port: 30W/27V DC
- Passive PoE voltage range: 27V DC
- LEDs
- RJ45 data ports:
- PoE
- Speed/link/activity
- SFP data ports:Link/activity
- RJ45 data ports:
- Software
- Management application:
- UISP: Version 1.4.0 and later
- Management application:
More Information
MFRPartNum:
UISP-S
