PRODUCT SPECIFICATIONS
220W (27V) PoE switch with (24) GbE RJ45 ports, including (16) with 27V passive PoE, and (4) 10G SFP+ ports.
Features:
- (24) GbE RJ45 ports, including (16) with 27V passive PoE output
- (4) SFP+ ports
- 220W (27V) total PoE availability, 15W/port (2-pair) / 30W/port (4-pair)
- Port isolation, speed limiting, and DHCP snooping functionality
- 1.3" LCM color touchscreen
- Additional Power TransPort input for DC redundancy
Technical Description
- Mechanical
- Dimensions: 442.4 x 267.5 x 43.7 mm (17.4 x 10.5 x 1.7")
- Weight: 4 kg (8.8 lb)
- Enclosure materials: SGCC steel, polycarbonate/acrylonitrile butadiene styrene
- Hardware
- Networking interface:
- (24) GbE RJ45 LAN ports
- (4) 1/10G SFP+ ports
- Management interface:
- Ethernet In-band
- Bluetooth
- Total non-blocking throughput: 64 Gbps
- Switching capacity: 128 Gbps
- Forwarding rate: 95.23 Mpps
- Power method:
- (1) Universal AC input, 100-240V AC, 4.4A Max., 50/60 Hz
- (1) Power TransPort DC input 27V DC, 9.3A
- Power supply:AC/DC, Internal, 250W
- Supported voltage range: 100-240V AC
- Max. power consumption: 30W (Excluding PoE output)
- ESD/EMP protection: Air: ± 15 kV, contact: ± 8 kV
- LCM display: (1) 1.3" touchscreen
- Operating temperature: -10 to 50° C (14 to 122° F)
- Operating humidity: 5 to 95% noncondensing
- Certifications: CE, FCC, IC
- Networking interface:
- PoE
- PoE interface: (16) 27V passive PoE: 2-pair (Pins 4, 5+/7, 8-) or 4-pair (Pins 1, 2, 4, 5+/3, 6, 7, 8-); Ports 1 to 16
- Total available PoE: 220W
- Max. passive PoE wattage per port: 30W/27V DC
- Passive PoE voltage range: 27V DC
- LEDs
- RJ45 data ports:
- PoE
- Speed/link/activity
- SFP+ data ports: Speed/link/activity
- RJ45 data ports:
- Software
- Management application:
- UISP: Version 1.5.7 and later
- Management application:
More Information
MFRPartNum:
UISP-S-Pro
