Ubiquiti USL-GlassBreak SuperLink Glass Break Motion Sensor 2km Range Battery Powered UniFi Protect

Ubiquiti USL-GlassBreak Glass Break Sensor

Battery-powered SuperLink sensor featuring advanced glass break detection and motion sensing.

Technical Specification

• Overview:
  • Dimensions: 134.5 x 24 x 22.5 mm (5.3 x 0.9 x 0.9')
  • Microphone: ✓
  • Mounting: Adhesive and screw mount
  • UniFi Application Suite:
    • Protect: ✓
• Performance:
  • Connectivity: SuperLink (Proprietary)
  • Operating Frequency:
    • US: 915.6–927.6 MHz
    • EU: 865.1–869.5 MHz
  • Antenna Gain:
    • SuperLink: 1 dBi
  • Max. TX Power:
    • SuperLink: 14 dBm
  • Max. Range:
    • SuperLink: 2 km (1.2 mi)
  • Sensor Features:
    • PIR Sensor: ✓
  • Detected Glass Type:
    • Plate, tempered, obscured, laminated, coated, wired
    • Size: 280 x 356 mm (11 x 14') to 1067 x 1626 mm (42 x 64”)
    • Thickness: 2.4 mm (3/32'), 4.8 mm (3/16'), 3.2 mm (1/8'), 6.4 mm (1/4')
• Hardware:
  • Max. Power Consumption: 0.2W
  • Supported Voltage Range: 3V
  • Power Method: (2) Lithium battery CR123A
  • Weight: With mount and batteries: 70 g (2.5 oz)
  • Enclosure Material: Polycarbonate
  • Mount Material: Polycarbonate
  • Buttons:
    • (1) Function button
    • (1) Factory-reset
    • (1) Tamper switch
  • LEDs:
    • (1) Status: R/B/W
    • (1) Signal: B/R
  • Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
  • Ambient Operating Humidity: 10 to 90% noncondensing
  • Certifications: FCC, IC, CE
  • NDAA Compliant: ✓
• Software:
  • Application Requirements:
    • Web Application: UniFi Protect
    • Mobile App: UniFi Protect iOS™ and Android™
