PRODUCT SPECIFICATIONS
SKU: UVC-AI-Bullet - AI Bullet
Indoor/outdoor 2K PoE camera with IR night vision and enhanced AI detection capabilities.
Features
- 2K (4MP) video resolution
- Advanced AI: Greater detection precision and range
- 9 m (30 ft) IR night vision
- Record audio with an integrated microphone
- Connect and power using PoE
- Weatherproof (outdoor exposed)
Dimensions
- Without mount: Ø82 x 88.3 mm (Ø3.23 x 3.48")
- With wall mount: Ø82 x 153 mm (Ø3.23 x 6.02")
Weight
- Without mount: 628 g (1.38 lb)
- With wall mount: 765 g (1.69 lb)
Technical Description
- Mechanical
- Enclosure materials: Aluminum alloy, polycarbonate
- Mounting materials: Wall mount: aluminum alloy
- Pole mount: aluminum alloy
- Weatherproofing: IP65
- Resistance: IK04
- Optics
- Sensor: 5MP CMOS sensor
- Lens: Fixed focal length
- View angle: H: 84.7°, V: 46.2°, D: 99°
- Night mode: Built-in IR LED illumination and an IR cut filter
- Video
- Video compression: H.264
- Resolution: 4MP 2688 x 1512 (16:9)
- Max. frame rate: 30 FPS
- Image settings: Brightness, contrast, sharpness, saturation, noise reduction, 50/60 Hz
- System
- Processor: Quad-core Arm® Cortex®-A53 based chip
- Networking interface: GbE RJ45 port
- Max. power consumption: 7.68W
- Power method: PoE
- Supported voltage range: 37—57V DC
- LED: R/G/B/W ring
- Button: Factory reset
- Mounting: Wall, pole mount (Included)
- Operating temperature: -20 to 40° C (-4 to 104° F)
- Operating humidity: 10 to 90% noncondensing
- Certifications: FCC, IC, CE
- Audio
- Microphone: Yes (Can be disabled)
- Software
- Web application: UniFi Protect: Version 1.20.0 and later
- Mobile app: UniFi Protect iOS™: Version 1.5.6 and later
- UniFi Protect Android™: Version 1.4.7 and later
