PRODUCT SPECIFICATIONS
Indoor/outdoor HD PoE camera with pan-tilt-zoom functionality that offers full 360° surveillance.
Features:
- Full HD, 30 FPS camera with a 5MP CMOS sensor
- Ultra-wide, 360° fisheye lens
- IPX4-rated, weatherproof casing
- IK08-rated tamper resistance
- Built-in IR LEDs for nighttime surveillance
360° Fish-eye Lens
- The ultra-wide, 360° fish-eye lens delivers an all-encompassing view of highly populated areas.
Built for the Outdoors
- A weather-resistant and IK08-rated, vandal-proof enclosure optimizes outdoor durability.
Indoor or Outdoor
- The all-weather design ensures reliable, high-quality performance even in the harshest conditions.
Vandal-proof Design
- The tamper-resistant, IK08-rated enclosure makes this camera ideal for monitoring large, public areas.
Easy to Mount
- Optimize your overhead surveillance coverage with a ceiling mounting.
Compatibilities
- POE
Technical Description
Optics
- Sensor
- 5 MP CMOS sensor
- Lens
- Fisheye lens
- View angle
- 360°
- Night mode
- Built-in IR LED illumination and IR cut filter
Video
- Video compression
- H.264, MJPG
- Resolution
- 1920 x 1920 (1:1)
- Maximum frame rate
- 30 FPS
- Image settings
- Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, masking, text overlay
Mechanical
- Dimensions
- Ø147 x 49 mm (Ø5.77 x 1.94")
- Weight
- Without mount: 655 g (1.44 lb)
- With outdoor accessory: 685 g (1.51 lb)
- Enclosure materials
- Aluminum alloy, polycarbonate, hard-coated dome
- Mounting materials
- Polycarbonate, stainless steel
- Weatherproofing
- IPX4
- Resistance
- IK08
More Information
MFRPartNum:
UVC-AI-360
