PRODUCT SPECIFICATIONS
Ubiquiti UVC-AI-360-W
Indoor/outdoor 2K PoE camera with pan-tilt-zoom functionality that offers full 360° surveillance.
Key Features:
- 2K (4MP) video resolution
- Ultra-wide 360° view
- 9 m (30 ft) IR night vision
- Advanced AI: Detect people, vehicles, and more
- Integrated 2-way audio
- Connect and power using PoE
- Weather-resistant (outdoor covered)
- Vandal resistant
Technical Specification
- Mechanical:
- Dimensions: Ø147 x 49 mm (Ø5.8 x 1.9')
- Weight:
- Without mount: 655 g (1.4 lb)
- With outdoor accessory: 685 g (1.5 lb)
- Enclosure material: Aluminum alloy, polycarbonate, hard-coated dome
- Mount material: Polycarbonate, stainless steel
- Weatherproofing: IPX4
- Resistance: IK08
- Optics:
- Sensor: 5MP CMOS
- Lens: Fisheye lens
- View angle: 360°
- Night mode: Built-in IR LED illumination and IR cut filter
- Video:
- Resolution: 4MP 1920 x 1920 (1:1)
- Max. frame rate: 30 FPS
- Image settings: Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, masking, text overlay
- System:
- Processor: Quad-core Arm® Cortex®-A53 based chip
- Networking interface: GbE RJ45 port
- Power method: PoE
- Power supply: 48V DC, 0.18A PoE
- Max. power consumption: 8.64W
- Supported voltage range: 37—57V DC
- LED: R/G/B/W
- Button: Factory reset
- Mounting: Surface mount
- Ambient operating temperature: -20 to 40° C (-4 to 104° F)
- Ambient operating humidity: 10 to 90% noncondensing
- Certifications: FCC, IC, CE
- Audio:
- Microphone: Yes (Can be disabled)
- Speaker: Yes
- Software:
- Web application: UniFi Protect: Version 1.10.0 and later
- Mobile app: UniFi Protect iOS™ and Android™
