PRODUCT SPECIFICATIONS
Ubiquiti UVC-G5-Dome-Ultra - G5 Dome Ultra
The Ubiquiti UVC-G5-Dome-Ultra is a compact, tamper-resistant 2K HD PoE camera designed for low-profile indoor security. Equipped with advanced night vision, wide viewing angles, and AI-powered event detection, this camera provides an ideal solution for discreet yet reliable surveillance.
The UVC-G5-Dome-Ultra provides exceptional image quality, advanced features, and durable design in a compact package, making it an excellent choice for secure and discreet indoor surveillance.
Key Features
- High-Definition Video:
- 2K (4MP) resolution at 2688 x 1512 (16:9) for clear and detailed footage.
- It captures a 120.6° diagonal viewing angle for comprehensive coverage.
- Night Vision:
- 20 m (65 ft) IR range for visibility in low-light conditions.
- Built-in IR LED illumination and IR cut filter for optimal night mode performance.
- Tamper-Resistant Design: IK06-rated enclosure ensures durability and protection against vandalism.
- AI Event Detection: Detects and records events with advanced AI technology.
- PoE Connectivity: Simplifies installation by combining power and network data over a single cable.
- Compact and Stylish: Ø2.5 x 2.7 inches for unobtrusive mounting in indoor environments.
- Integration: Fully compatible with UniFi Protect software for seamless management and playback.
Applications
- Home Security: Low-profile and discreet for monitoring living spaces.
- Office Surveillance: Ideal for entryways and workspaces requiring subtle security.
- Retail Monitoring: Prevent theft and vandalism while maintaining aesthetic appeal.
Technical Specifications
- Mechanical
- Dimensions: Ø63.6 x 68.2 mm (Ø2.5 x 2.7').
- Weight: 175 g (6.2 oz).
- Enclosure Material: Aluminum alloy, polycarbonate.
- Mount Material: Stainless steel.
- Resistance: IK06-rated.
- Color: Black.
- Optics
- Sensor: 1/2.4' CMOS.
- Lens: Fixed focal length.
- View Angle:
- Horizontal: 102.4°.
- Vertical: 54.9°.
- Diagonal: 120.6°.
- Night Mode: Built-in IR LED illumination and IR cut filter.
- IR Distance: 20 m (65 ft).
- Video
- Resolution: 4MP (2688 x 1512, 16:9).
- Max Frame Rate: 30 FPS.
- Image Settings: Color, brightness, sharpness, contrast, Black balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay.
- System
- Processor: Dual-core Arm® Cortex®-A7 chip.
- Networking Interface: 10/100 MbE RJ45 port.
- Max Power Consumption: 4.2W.
- Power Method: PoE (37–57V DC).
- Button: Factory reset.
- Mounting: Surface mount.
- Operating Conditions:
- Temperature: -20 to 40º C (-4 to 104º F).
- Humidity: 10 to 90% noncondensing.
- Certifications: FCC, IC, CE.
- Software
- Web Application: UniFi Protect.
- Mobile App: UniFi Protect for iOS™ and Android™.
More Information
MFRPartNum:
UVC-G5-Dome-Ultra-B
