PRODUCT SPECIFICATIONS
Aluratek ATL01F Bio-Key TouchLock XL Fingerprint Padlock
The Aluratek ATL01F Bio-Key TouchLock XL is a rechargeable biometric padlock that uses fingerprint recognition for everyday access. Store up to 20 fingerprints to provide access for family members or other authorized users without sharing physical keys.
Designed for applications such as lockers, sheds, gates and bicycle locking arrangements, the ATL01F combines fingerprint access with a personalized Fast-Click backup code. Physical suitability depends on the attachment point and shackle clearance.
Key Features
- Fingerprint recognition with storage for up to 20 fingerprints.
- Fast-Click backup unlocking through a personalized sequence of shackle presses.
- Built-in rechargeable battery.
- Micro-USB charging with an included USB cable.
- Red and blue status indicators.
- Water-resistant rubber ring.
Fingerprint and Backup Access
Press the shackle to activate the lock, then place an enrolled finger on the sensor. Fast-Click provides an alternative unlocking method using six short or long presses. Configure this personalized sequence immediately after enrolling the first fingerprint.
Rechargeable Operation
The micro-USB connection provides convenient recharging. If the battery becomes depleted while locked, the manufacturer’s guide instructs users to supply power from an external battery before unlocking.
Ideal Applications
- Lockers with suitable padlock openings.
- Shed and gate hasps after checking physical fit.
- Shared access requiring multiple enrolled fingerprints.
- Bicycle locking arrangements with suitable attachment hardware.
Compatible Products
The ATL01F is a standalone padlock. Mechanical compatibility requires a hasp, chain, cable loop or other attachment opening that accommodates the shackle and allows it to close fully.
Important: Overall lock dimensions do not establish attachment compatibility. Verify the installation opening before ordering.
Technical Specifications
General
- Brand: Aluratek
- Model / MPN: ATL01F
- Product Family: Bio-Key TouchLock XL
- Product Type: Biometric fingerprint padlock
Access and Controls
- Primary Access: Fingerprint recognition
- Fingerprint Capacity: Up to 20 fingerprints
- Backup Access: Six-step Fast-Click sequence of short and long shackle presses
- Activation: Press the shackle
- Status Indicators: Red and blue LEDs
- Automatic Power-Off: After 15 seconds without activity
Power and Charging
- Power Source: Built-in rechargeable battery
- Battery Capacity: 60 mAh
- Charging Interface: Micro-USB
- Advertised Charging Time: 2 hours
- Advertised Battery Life: Up to one year per charge; actual results vary
Physical and Environmental
- Overall Dimensions: 1.875 x 0.875 x 2.875 inches
- Weight: 5 oz.
- Ingress Protection: IP54
Warranty and Included Parts
- Warranty: One-year limited manufacturer warranty
- ATL01F Bio-Key TouchLock XL padlock
- USB charging cable
