PRODUCT SPECIFICATIONS
A320i - Android Touch Screen Console IP Phone
The A320i is tailored for industry use, featuring a goose-neck microphone and HD hands-free calling. With 116 DSS keys, a 10.1-inch touch screen, Wi-Fi, and Bluetooth, it streamlines daily communication. Equipped with an adjustable camera and an HD PTM handset, it enhances audio and video experiences for group conferences. Compatible with SIP, it's perfect for management or command centers, offering functions like video calls, intercom, monitoring, and broadcasting.
Highlights
- 20 SIP lines, 10-party audio conference,3-party video conference
- Equipped with a PTM handset, a standard/PTT handset is optional.
- Equipped with a goose-neck microphone for further sound pickup distance
- Integrate public address software to build a broadcasting system
- Built-in adjustable 8 mega-pixel camera with a privacy cover
- 112 DSS soft keys on 10.1” touch screen
- HD audio on speaker and handset
- Support Bluetooth 5.0 and 2.4G/5G Wi-Fi
- Video Codec H.264, supports video calls.
- Dual Gigabit ports, PoE Integrated.
Technical Description
- Generic
- 20 SIP Lines
- HD Voice
- Support Video Call
- PoE Enabled
- 10.1-inch (1280x800) touch screen
- Handset / Hands-free / Headset mode
- Intelligent DSS Keys (virtual buttons)
- Operation System
- Android 9.0 OS with higher security and better compatibility
- Built-in applications: Files, Calendar, Gallery, Browser, Email, Calculator, Notepad, Sound Recorder, Clock, Video, Music
- Secondary development of API
- Support third-party applications installation.
- Phone Features
- Remote phonebook (XML/LDAP, 2000 entries)
- Intelligent search for contacts and call Log
- Call logs (In/out/missed, 1000 entries)
- Voice message waiting indication (VMWI) programmable DSS/Soft keys
- Network time synchronization
- Built-in Bluetooth 5.0
- Built-in Wi-Fi
- 2.4GHz, 802.11 b/g/n
- 5GHz, 802.11 a/n/ac
- Action URL / Active URI
- UaCSTA
- Audio/Video recording
- SIP Hotspot
- Group broadcasting
- Action plan
- Group listening
- Video
- Video decoding: H.264, H.265(optional)
- Video call resolution: CIF/VGA/4CIF/720P/1080P
- Image format: JPEG/PNG/BMP
- Video format: MP4
- Bandwidth selection: 64kbps~4Mbps
- Frame rate selection: 5~30fps
- Video from remote site can be displayed in full screen
- Video call
- Video Preview
- Camera
- 8 mega-pixel (Adjustable Angle)
- Mechanical shutter for privacy
- Audio
- HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
- HAC handset
- Wideband ADC/DAC 16KHz Sampling
- Narrowband Codec: G.711a/u, G.729AB, iLBC
- Wideband Codec: G.722, Opus
- Full-duplex Acoustic Echo Canceller (AEC)
- Noise Reduction (NR)
- Packet Loss Concealment (PLC)
- Dynamic Adaptive Jitter Buffer
- DTMF: In-band, Out-of-Band – DTMF-Relay (RFC2833) / SIP INFO
- Network
- Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
- IP Mode: IPv4
- IP Configuration: Static / DHCP
- Network Access Control: 802.1x
- VPN: OpenVPN (Requires third-party app support)
- VLAN
- LLDP
- CDP
- QoS
More Information
MFRPartNum:
A320i
Datasheet:
