PRODUCT SPECIFICATIONS
MikroTik GPERx6 CSS606-1G-2Gi-3S+OUT Outdoor PoE & Fiber Switch
The MikroTik GPERx6 CSS606-1G-2Gi-3S+OUT is a rugged outdoor IP66-rated Cloud Smart Switch designed to simplify long-distance network deployments by combining fiber connectivity and power distribution in a single outdoor-ready device.
Built for harsh environments, the GPERx6 helps reduce cable clutter by allowing installers to extend power and fiber together using hybrid cabling. At the remote end, the switch neatly separates connectivity into 10G SFP+ uplinks, PoE-out ports, and DC outputs for powering additional switches, access points, cameras, IoT devices, or specialized equipment.
The device includes 3 Gigabit Ethernet ports, 3 x 10G SFP+ cages, PoE-in on Ether1, passive PoE-out on Ether2 and Ether3, and 3 DC-out ports. Powered by MikroTik SwOS and a dedicated 10G switch chip, the GPERx6 is ideal for WISP, ISP, surveillance, campus, industrial, perimeter, and outdoor fiber network applications.
Key Features
- Outdoor IP66-rated enclosure for harsh environments
- 3 x Gigabit Ethernet ports
- 3 x 10G SFP+ ports for long-distance fiber uplinks
- PoE-in support on Ether1
- Passive PoE-out on Ether2 and Ether3
- 3 x DC output ports for IoT devices or specialized equipment
- Dedicated 10G switch chip: 88E6193X
- Supports hybrid fiber + copper cable deployments
- SwOS management for lightweight Layer 2 switching
- Operating temperature range from -40°C to +70°C
- Maximum power consumption up to 160W
- Includes hose clamp and fastening set
Hybrid Fiber and Power Deployment
The GPERx6 is designed for installations where long-distance fiber and power must be delivered together. Fiber strands carry high-speed network data, while copper conductors deliver DC power. At the far end, the GPERx6 distributes that connection through SFP+ uplinks, PoE-out ports, and DC outputs.
This makes it especially useful for large campuses, estates, industrial parks, ports, perimeter networks, surveillance systems, and solar-powered edge deployments where fewer cable runs mean cleaner installations and easier maintenance.
Built for Tough Outdoor Networks
With its heavy-duty IP66 enclosure, the CSS606-1G-2Gi-3S+OUT is built to handle outdoor conditions including heat, cold, wind, rain, and dust. Its wide operating temperature range and passive design make it suitable for demanding remote deployments.
Flexible Powering Options
The GPERx6 supports multiple power options including a 2-pin DC screw terminal and 802.3bt PoE-in. It can also provide passive PoE-out and DC output power to compatible downstream devices, reducing the need for separate outdoor power supplies.
Ideal Applications
- WISP and ISP outdoor infrastructure
- Hybrid fiber and DC power deployments
- Perimeter surveillance networks
- Outdoor access point and switch powering
- Industrial parks, campuses, estates, and ports
- IoT deployments using DC output power
- Solar-powered edge network installations
- Long-distance fiber network extensions
Technical Specifications
- Hardware
- Product Code: CSS606-1G-2Gi-3S+OUT
- Product Name: MikroTik GPERx6
- Switch Chip: 88E6193X dedicated 10G switch chip
- Operating System: SwOS
- Enclosure Rating: IP66
- Dimensions: 406 x 116 x 76 mm
- Ethernet & Fiber Interfaces
- Gigabit Ethernet Ports: 3 x 1G Ethernet ports
- PoE-In Port: Ether1
- PoE-Out Ports: Ether2 and Ether3
- SFP+ Ports: 3 x 10G SFP+ ports
- Power
- DC Inputs: 2 total: 2-pin screw terminal and PoE-in
- 2-Pin Screw Terminal Input Voltage: 12–57V DC
- PoE-In Voltage: 42–57V DC
- PoE-In Standard: 802.3bt
- PoE-Out Type: Passive PoE up to 57V on Ether2–Ether3
- Max Output Per Port: 1.2A when input voltage is below 30V
- Max Output Per Port: 0.625A when input voltage is above 30V
- Maximum Total PoE Output: 2.4A
- DC-Out Ports: 3 ports, DC1–DC3
- Maximum Total DC-Out: 3.6A
- Maximum Power Consumption Without Attachments: 6W
- Maximum Power Consumption: 160W
- Environmental
- Operating Temperature: -40°C to +70°C
- Outdoor Protection: Heavy-duty IP66 enclosure
- Included Accessories
- Hose clamp
- Fastening set
