PRODUCT SPECIFICATIONS
Mikotik DDQ+85MP01D
QSFP-DD optical module for reliable 400G fiber connections within ultra-fast setups, like the CRS812 and CRS804.
The module includes built-in digital diagnostics for optical power, voltage, temperature, laser bias current, and other key parameters. These functions help detect abnormal activity or when customizable operating limits are exceeded. Monitoring makes it easier to plan ahead, make informed decisions, and schedule upgrades or maintenance based on real performance data.
This is an optical module with an MTP/MPO connector that requires Female-Female Type-B polarity MTP/MPO-16 optical cable. The module offers eight independent full-duplex channels with up to 50 Gbps per channel bandwidth and an aggregate bandwidth of 400 Gbps.
Key Features
- 400 Gigabit High‑Speed Fiber Connectivity
- QSFP‑DD Form Factor
- MTP/MPO Connector
- Up to 100 Meter Reach
- Digital Diagnostic Monitoring (DDM)
- 8‑Lane Full‑Duplex Support
- Reliable Optical Module for Fiber Networks
- Ideal for 400G‑Capable Switches
- Specifications:
- MTBF: Approximately 200'000 hours at 25C
