PRODUCT SPECIFICATIONS
MikroTik EG25-G&SXTsq - SXTsq Embedded LTE4 Global
The MikroTik SXTsq Embedded LTE4 Global is a cost-effective outdoor LTE device built for reliable remote connectivity. It combines an integrated 2x2 MIMO directional antenna, LTE Cat4 modem, RouterOS v7, eSIM support, and a rugged IP67-rated SXTsq outdoor enclosure.
This Global version uses the EG25-G modem and includes expanded LTE band support for North America and global deployments. It is designed for outdoor installation where fixed broadband may not be available, with PoE-in power and low 5 W maximum power consumption.
Outdoor LTE Connectivity
The integrated directional antenna helps improve signal quality and stability when the device is mounted outdoors and pointed toward the nearest LTE tower. The device supports LTE Cat4 with 150 Mbps downlink and 50 Mbps uplink, plus 2x2 MIMO downlink support.
RouterOS v7 Networking
Powered by RouterOS v7, the SXTsq Embedded LTE4 Global supports MikroTik networking functions including advanced routing, firewall and VPN support, remote management, traffic control, monitoring, automation, and scripting.
Key Features
- Outdoor LTE Cat4 device with integrated 2x2 MIMO directional antenna
- Global EG25-G modem version with expanded LTE band support
- Built-in eSIM support with one Nano SIM slot
- RouterOS v7 operating system with RouterOS license level 3
- One 10/100/1000 Ethernet port
- PoE-in support with passive cooling
- IP67-rated outdoor enclosure
- 5 W maximum power consumption
Applications
- Rural homes where traditional broadband may not reach
- Cabins and remote locations needing LTE internet access
- Construction sites requiring temporary or distributed connectivity
- Backup connections and remote deployments using eSIM or Nano SIM service
- International and multi-region LTE deployments using the Global modem version
Technical Specifications
- Ports / Interfaces
- 10/100/1000 Ethernet ports: 1
- Number of SIM slots: 1 Modem (Nano SIM)
- eSIM: Yes
- Wireless
- LTE Category: 4 (150Mbps Downlink, 50Mbps Uplink)
- MIMO DL: 2x2
- MIMO UL: 1x1
- 2G Category: Class33
- 2G bands: 2 (1900MHz), 3 (1800MHz), 5 (850MHz), 8 (900MHz)
- 3G Category: R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
- 3G bands: 1 (2100MHz), 2 (1900MHz), 4 (1700MHz), 5 (850MHz), 6 (850 MHz), 8 (900MHz), 19 (800 MHz)
- LTE FDD bands: 1 (2100MHz), 2 (1900MHz), 3 (1800MHz), 4 (1700MHz), 5 (850MHz), 7 (2600MHz), 8 (900 MHz), 12 (700MHz), 13 (700 MHz), 18 (800 MHz), 19 (800 MHz), 20 (800MHz), 25 (1900MHz), 26 (850MHz), 28 (700MHz)
- LTE TDD bands: 38 (2600MHz), 39 (1900MHz), 40 (2300MHz), 41 (2500MHz)
- TAC: 01678800
- Hardware
- Product code: EG25-G&SXTsq
- Architecture: ARM 32bit
- CPU: Cortex A7
- CPU core count: 1
- CPU nominal frequency: 800 MHz
- Size of RAM: 256 MB
- Storage size: 256 MB
- Storage type: NAND
- CPU temperature monitor: Yes
- Cooling type: Passive
- Included parts: 24V 0.38A power adapter, Gigabit PoE injector, Hose clamp 1
- Power
- Number of DC inputs: 1 (PoE-IN)
- Max power consumption: 5 W
- PoE in: 802.3af/at
- PoE in input Voltage: 12-28 V
- Environmental
- Tested ambient temperature: -40°C to 70°C
- IP: 67
- MTBF: Approximately 100'000 hours at 25C
- Software
- Operating System: RouterOS v7
- RouterOS license: 3
- Certifications
- Certification: CE, EAC, ROHS
