Part:
GESP

Mikrotik Gigabit Ethernet Surge Protector RJ45 Male/Female Conector

$29.00

PRODUCT SPECIFICATIONS

SKU: GESP

Mikrotik GESP Gigabit Ethernet Surge Protector

GESP is Gigabit Ethernet Surge Protector that can be used to protect the network from lightning or surge damages.

Here’s what a typical use-case would be like. You have a mast with some antennas. And some switches on the ground. Put the GESP surge protectors on each end. They come sealed inside a new and improved IP67 weatherproof enclosure. Your antennas are now safe during a lightning storm.

Don’t forget about the grounding wire! Secure it to the rackmount, mast, or any other structure that is connected to the ground. For maximum protection, you should use a surge protector on both ends of long cables.

You can’t buy safety, but you can buy an RBGESP surge protector and keep your setup safe. RBGESP is Gigabit Ethernet Surge Protector that can be used to protect the network from lightning or surge damages

The GESP units can usually absorb multiple impacts, but make sure to check their condition after each surge. For the attachment of GESP units, we recommend using PVC zip ties. Just don’t make it too tight.

You know what they say – hope for the best, prepare for the worst. This small investment can save you lots of time and money, so why risk it? Grab a GESP and put your mind at ease!



Technical Description

Interface connections

  • RJ45 Male/Female Conector

ESD/EMP protection

  • Absorbing transient current with response to surge voltage of 100 V/s 1 kV/μs
  • ESD, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61643-21, ±8 kV contact, ±15 kV air

DC spark-over voltage

  • 75 V @ 100 V/s

Maximum impulse spark-over voltage

  • 700 V @ 1 kV/μs

Discgarge current

  • 3 kA (8/20μs)

Minimum insulation resistance

  • 1 G ohm @ 50V

Maximum capacitance

  • 4 pF @ 1 MHz

Data line protecion

  • RJ45 10/100/1000 Ethernet

PoE support Passive

  • PoE

IP rating

  • IP67

Operating temperature

  • -40 to 70°C

More Information

MFRPartNum:
GESP
