Mikrotik

Part:
RB4011iGS+5HacQ2HnD-IN

MikroTik MikroTik RouterBOARD 10xGigabit port, SFP+ 10Gbps cage (International Version)

$230.95
$231.95
Condition:
New

PRODUCT SPECIFICATIONS

SKU: RB4011iGS+5HacQ2HnD-IN - Powerful 10xGigabit port router with a Quad-core 1.4Ghz CPU, 1GB RAM, SFP+ 10Gbps cage, dual band 2.4GHz / 5GHz 4x4 MIMO 802.11a/b/g/n/ac wireless and desktop case.

RB4011 series - amazingly powerful routers with ten Gigabit portsSFP+ 10Gbps interface and IPsec hardware acceleration for a great price!

The RB4011 uses a quad core Cortex A15 CPU, same as in our carrier grade RB1100AHx4 unit. The unit is equipped with 1GB of RAM, can provide PoE output on port #10 and comes with a compact and professional looking solid metal enclosure in matte black.

RB4011iGS+5HacQ2HnD-IN (WiFi model) is dual bandfour chain unit with a supported data rate of up to 1733 Mbps in 5GHz. For legacy devices, the unit also has a dual chain 2GHz wireless card installed in miniPCI-e slot.

RB4011iGS+5HacQ2HnD-IN (International) supports 2412-2484MHz and 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).

Note: Passive DAC (MikroTik S+DA0001/S+DA0003) are not supported

Technical Description

  • Specifications
    • Product code: RB4011iGS+5HacQ2HnD-IN
    • Architecture: ARM 32bit
    • CPU: AL21400
    • CPU core count: 4
    • CPU nominal frequency: auto (533 - 1900) MHz
    • Switch chip model: RTL8367SB
    • Dimensions: 228 x 120 x 30 mm
    • RouterOS license: 5
    • Operating System: RouterOS v7
    • Size of RAM: 1 GB
    • Storage size: 512 MB
    • Storage type: NAND
    • MTBF: Approximately 200'000 hours at 25C
    • Tested ambient temperature: -40°C to 45°C
    • IPsec hardware acceleration: Yes
  • Wireless capabilities
    • Wireless 5 GHz Max data rate: 1733 Mbit/s
    • Wireless 5 GHz number of chains: 4
    • Wireless 5 GHz standards: 802.11a/n/ac
    • Antenna gain dBi for 5 GHz: 3
    • Wireless 5 GHz chip model: QCA9984
    • Wireless 5 GHz generation: Wi-Fi 5
    • Wireless 2.4 GHz Max data rate: 300 Mbit/s
    • Wireless 2.4 GHz number of chains: 2
    • Wireless 2.4 GHz standards: 802.11b/g/n
    • Antenna gain dBi for 2.4 GHz: 3
    • Wireless 2.4 GHz chip model: R11e-2HnD
    • Wireless 2.4 GHz generation: Wi-Fi 4
    • WiFi speed: AC2000
  • Ethernet
    • 10/100/1000 Ethernet ports: 10
  • Fiber
    • SFP+ ports: 1
  • Peripherals
    • MiniPCI-e slots: 1
    • Serial console port: RJ45
  • Powering
    • Number of DC inputs: 2 (PoE-IN, DC jack)
    • DC jack input Voltage: 12-57 V
    • Max power consumption: 44 W
    • Max power consumption without attachments: 23 W
    • Cooling type: Passive
    • PoE in: Passive PoE
    • PoE in input Voltage: 18-57 V
  • PoE-out
    • PoE-out ports: Ether10
    • PoE out: Passive PoE up to 57V
    • Max out per port output (input 18-30 V): 600 mA
    • Max out per port output (input 30-57 V): 420 mA
    • Max total out (A): 600 mA
  • Certification & Approvals
    • Certification: CE, FCC, IC, EAC, ROHS
    • IP: IP20
  • Other
    • PCB temperature monitor: Yes
    • Voltage Monitor: Yes

More Information

MFRPartNum:
RB4011iGS+5HacQ2HnD-IN
Datasheet:
