PRODUCT SPECIFICATIONS
The RB3011 is a new multi port device, our first to be running an ARM architecture CPU for higher performance than ever before. The RB3011 has ten Gigabit ports divided in two switch groups, an SFP cage and for the first time a SuperSpeed full size USB 3.0 port, for adding storage or an external 3G/4G modem.
RB3011UiAS-RM Unit comes with 1U rackmount enclosure, a touchscreen LCD panel, a serial console port and PoE output functionality on the last Ethernet port.
Specifications
- Product code RB3011UiAS-RM
- Architecture ARM 32bit
- CPU IPQ-8064
- CPU core count 2
- CPU nominal frequency 1.4 GHz
- Dimensions 443 x 92 x 44 mm
- License level 5
- Operating System RouterOS
- Size of RAM 1 GB
- Storage size 128 MB
- Storage type NAND
- Tested ambient temperature -20°C to 70°C
Powering
- PoE in Passive PoE
- PoE in input Voltage 10-30 V
- Number of DC inputs 2 (DC jack, PoE-IN)
- DC jack input Voltage 10-30 V
- Max power consumption 30 W
- Max power consumption without attachments 10 W
PoE-out
- PoE-out ports Ether10
- PoE out Passive PoE
- Max out per port output (input < 30 V) 600 mA
- Max total out (A) 600 mA
Ethernet
- 10/100/1000 Ethernet ports 10
Fiber
- SFP ports 1
Peripherals
- Serial port RJ45
- Number of USB ports 1
- USB Power Reset Yes
- USB slot type USB 3.0 type A
- Max USB current (A) 1
Other
- PCB temperature monitor Yes
- Voltage Monitor Yes
Certification & Approvals
- Certification CE/RED, EAC, ROHS
More Information
MFRPartNum:
RB3011UiAS-RM
