Mikoritk hAP Lite Wireless Access Point



SKU: RB941-2nD - The home Access Point lite (hAP lite) is an ideal little device for your apartment, house or office.

It supports button triggered WPS, for the convenience of not typing a complicated password when somebody wants to have wireless internet access, and can also be told to change to cAP mode and join a CAPsMAN centrally managed network by the push of a button.

Of course, the device runs RouterOS with all the features, bandwidth shaping, firewall, user access control and many others.

The hAP lite is equipped with a powerful 650MHz CPU32MB RAMdual chain 2.4GHz onboard wirelessfour Fast Ethernet ports and a RouterOS L4 licenseUSB power supply is included.

Technical Description

  • Specifications
    • Product code: RB941-2nD
    • Architecture: SMIPS
    • CPU: QCA9533
    • CPU core count: 1
    • CPU nominal frequency: 650 MHz
    • Switch chip model: QCA9533-BL3A
    • RouterOS license: 4
    • Operating System: RouterOS
    • Size of RAM: 32 MB
    • Storage size:16 MB
    • Storage type: FLASH
    • MTBF: Approximately 100'000 hours at 25C
    • Tested ambient temperature: -20°C to 60°C
  • Wireless capabilities
    • Wireless 2.4 GHz Max data rate: 300 Mbit/s
    • Wireless 2.4 GHz number of chains: 2
    • Wireless 2.4 GHz standards: 802.11b/g/n
    • Antenna gain dBi for 2.4 GHz: 1.5
    • Wireless 2.4 GHz chip model: QCA9533
    • Wireless 2.4 GHz generation: Wi-Fi 4
  • Ethernet
    • 10/100 Ethernet ports: 4
  • Powering
    • MicroUSB input Voltage: 5-5 V
    • Number of DC inputs: 1 (MicroUSB)
    • Max power consumption: 3.5 W
    • Cooling type: Passive
  • Certification & Approvals
    • Certification: FCC, IC
