NetPoint Antennas

Part:
NP-PRO-S32

Netpoint 3-Ft Twist-on Parabolic Antenna DP 4.9-6.4 GHz 32 dBi Comp w C5x and B5x w/Twinwav

$454.95
Condition:
New

PRODUCT SPECIFICATIONS

NP-PRO-S32 - A flexible solution for using mimosa Twist-on radios and antennas with jumpers.

The Twist-on antenna by NetPoint offers a cost effective, dual polarized, 4.9-6.4 Ghz, up to 31 miles (50km), 3ft parabolic antenna engineered to deliver reliable radio links with a stable 32 dBi gain from 4.9 to 6.4 GHz. Designed for U-NII-1, -2A, -2C, -3 and public safety applications.

FEATURES AND BENEFITS

  • Gain of up to 32 dBi with low VSWR and high port isolation across the entire 4.9-6.4 GHz band
  • One antenna that covers 5 and 6 Ghz
  • Simplifies installation on site and guarantees “factory-tested” quality
  • Connector type Twist-on

Technical Description

  • ELECTRIC SPECIFICATIONS
    • Antenna Type: Modular dish twist - on
    • Frequency: 4.9 - 6.4 Ghz
    • Connector Type: Twist-on
    • Gain (dBi): 30, 31, 32 4.9GHz, 5.5GHz and 6.4GHz
    • VSWR HPOL: <2.0
    • Beamwidth VPOL: 4.0°
    • Beamwidth HPOL: 4.2°
    • Radius F/B (dB):  >25
    • Polarization: Dual slant 45°
    • Impedance (Ohms): 50
  • MECHANICAL SPECIFICATIONS
    • Wind Max Survival Speed(MPH): 74.56 miles |120km with Radome
    • Azimuth Adjustment: +/- 60 degrees
    • Elevation Adjustment (°): +/- 20 degrees
    • Mounting Pipe Diameter, Min: 1 inch - 25.4mm
    • Mounting Pipe Diameter, Max: 2.750 inch 69.86mm
    • Operating Temperature (C°): -49 to +140 F° | -45 to +60 C°

More Information

MFRPartNum:
NP-PRO-S32
Datasheet:
