NetPoint NPPRO UW30 twist on parabolic antenna 30.1 dBi 4.9 to 7.2 GHz dual polarity

NetPoint NPPRO-UW30 Twist-on parabolic antenna

NetPoint's high-performance NPPRO-UW30 twist-on parabolic antenna is designed for very high performance in unlicensed bands with excellent gain. The NPPRO UW30 model has dual polarization, as well as exceptional VSRW performance in the 4.9 to 7.2 Ghz operating band. The antenna comes pre-assembled and ready to install, as well as an integrated radome for high performance and reliable operation in the most demanding conditions. This 2.3-foot parabolic antenna can be used for PTP backhaul, CPE and public safety applications.

Key Features

• Up to 30.1 dBi gain, with low VSWR and high port isolation across the entire 4.9 to 7.2 GHz band.
• Antenna with extended coverage up to 6 GHz.
• Simplifies on-site installation while ensuring factory-tested quality.
• Equipped with a twist-on connector for quick and easy assembly.

Technical Specification:

• Electrical Specifications:
  • Type of antenna: Modular dish twist - on
  • Frequency: 4.9 a 7.2 Ghz
  • Connector type: Twist-on
  • Gain (dBi):
    • Low: 28
    • Medium: 29
    • High: 30.1
  • VSWR: <2.0
  • Beamwidth VPOL: 4.4°
  • Beamwidth HPOL: 4.0°
  • Radius F/B (dB): 44
  • Polarization: Dual slant 45°
• Mechanical Specifications
  • Maximum survival wind speed (MPH): 124,27 miles with Radome
  • Azimuth adjustment: +/- 60 degrees
  • Elevation adjustment (°): +/- 15 degrees
  • Mounting tube diameter, min.: 1 inch - 25.4mm
  • Mounting tube diameter, max.: 2.750 inch 69.86mm
  • Operative temperature (C°): -49 to +140 F° | -45 to +60 C°
