PRODUCT SPECIFICATIONS
NetPoint NPPRO-UW Twist-on parabolic antenna
NetPoint's high-performance NPPRO-UW twist-on parabolic antenna is designed for very high performance in unlicensed bands with excellent gain. The NPPRO UW model has dual polarization twist-on compatibility with B5x and C5X, as well as exceptional VSRW performance in the 4.9 to 7.2 Ghz operating band. The antenna comes pre-assembled and ready to install, as well as an integrated radome for high performance and reliable operation in the most demanding conditions. This 1.3-foot parabolic antenna can be used for PTP backhaul, CPE and public safety applications.
Key Features
- Up to 26 dBi gain with low VSWR and high port isolation over the entire 4.9 to 7.2 Ghz band
- An antenna covering 6 Ghz
- It facilitates on-site installation and guarantees “factory-tested” quality.
- Twist on connector
- Electrical Specification:
- Type of antenna: Modular dish twist - on
- Frequency: 4.9 a 7.2 Ghz
- Connector type: Twist-on
- Gain (dBi):
- Low: 24
- Medium: 25
- High: 26
- VSWR HPOL: <2.0
- Beamwidth VPOL: 8.2°
- Beamwidth HPOL: 8.0°
- Radius F/B (dB): 50
- Polarization: Dual slant 45°
- Mechanical Specification:
- Maximum survival wind speed (MPH): 124,27 miles with Radome
- Azimuth adjustment: +/- 60 degrees
- Elevation adjustment (°): +/- 15 degrees
- Mounting tube diameter, min.: 1 inch - 25.4mm
- Mounting tube diameter, max.: 2.750 inch 69.86mm
- Operative temperature (C°): -49 to +140 F° | -45 to +60 C°
More Information
MFRPartNum:
NPPRO-UW
