PRODUCT SPECIFICATIONS
The TIP-200 Fiber Connector Microscope is designed for inspecting fiber connectors. It supports both 1.25mm and 2.5mm connectors. It provides high magnification and clarity for accurate inspection of fiber end faces. The microscope is equipped with a built-in light source and offers adjustable focus for clear visualization. It is a compact and portable device, ideal for field inspections and maintenance tasks.
Features
- The amplification rates of 200 times are switched to each other.
- lmported coated lens, stain clearlyvisible.
- White LED, rated for 100,000 hours;40 hour battery life.
- Grinded silica gel shell, anti-skid,anti-fall and anti-shock.
- Supporting sC/FC/ST/LC
- 1.25 mm & 2.5mm adapter
- Small size, one-handed,convenient and fast.
Dimensions
- 225mm x 60mm x 42mm
Technical Description
- Magnification: 200x
- Light Source: White LED, rated for 100,000 hours; 40 hour battery life
- Adapter Interface: 1.25 mm & 2.5mm universal adapter included
- Interface type: SC, FC, ST and LC
- Include: Host machine, 1.25 mm & 2.5mm adapter Nylon black bag, Packing box
More Information
MFRPartNum:
TIP-200
Datasheet:
