PRODUCT SPECIFICATIONS
TSW114 - GIGABIT DIN RAIL ETHERNET SWITCH
TSW114 is an affordable way to simplify your connectivity with its plug and play nature and 5 x Gigabit Ethernet ports that provide stable and reliable connectivity for high-bandwidth solutions. The Ethernet switch has front-facing ports and an integrated DIN rail bracket to enable easy installation across many industrial environments - especially control cabinets.
Features
- EASY MOUNTING: Integrated DIN rail bracket and front-facing ports
- GIGABIT ETHERNET: 5 x Gigabit Ethernet ports with speeds of up to 1000 Mbps
- COMPACT & DURABLE: Rugged anodized aluminum housing that fits in your pocket
- PLUG AND PLAY: No additional configuration needed
Dimensions
- 113.1 x 27.4 x 80.5 mm
Weight
- 174 g
Technical Description
- ETHERNET
- ETH:5 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
- IEEE 802.3 series standards:802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
- PERFORMANCE SPECIFICATIONS
- Bandwidth (Non-blocking): 10 Gbps
- Packer buffer: 128 KB
- MAC address table size: 2K entries
- Jumbo frame support: 9216 bytes
- POWER
- Connector: 2-pin industrial DC power socket
- Input voltage range: 9 – 30 VDC
- PoE (passive): Possibility to power up through ETH1 ports, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 30 VDC
- Power consumption: Idle: 0.3 W / Max: 2.3 W
- PHYSICAL INTERFACES
- Ethernet: 5 x RJ45 ports, 10/100/1000 Mbps
- Status LEDs: 1 x Power LED, 10 x ETH status LEDs
- Power:1 x 2-pin industrial DC power socket
- Other:1 x Grounding screw
More Information
MFRPartNum:
TSW114
