Tycon Power Systems

Part:
POE-EXT-GD-HP

Tycon Outdoor Gigabit PoE Extender. 802.3at in/out. Extends Ethernet and PoE an extra 100M. 2pair or 4pair passive or active PoE input

$86.30
$99.95
Condition:
New

PRODUCT SPECIFICATIONS

The POE-EXT-GD-HP is a high quality, high power, shielded Gigabit Ethernet and PoE extender to be able to extend Ethernet beyond the standard 100m limit. By using multiple units, Ethernet and PoE can be extended up to 300m over CAT5/CAT6 cables. The units are powered by PoE so no additional power source is required. Units can accept Mode A (Pins 1,2,3,6) or Mode B (Pins 4,5,7,8) PoE: 802.3af, 802.3at or 48V Passive PoE.

The rugged outdoor weatherproof enclosures are powder coated aluminum and are rated to IP66. The units meet outdoor temperature ratings of -25C to +55C.

Features

  • 802.3af / 802.3at Compatible
  • 10/100/1000Mb Compatible
  • Weatherproof – Outdoor rated
  • Easy Plug and Play Operation
  • Extends PoE an additional 100m
  • Auto Link Speed, Duplex and Crossover

Applications

  • Wireless Equipment
  • IP Telephone
  • Security Applications
  • Sensor Equipment

Dimensions (LxWxH)

  • 7.3 x 1.8 x 1.8” (185x45x45mm)

Weight

  • 8.5oz (240g)

Technical Description

  • PoE Input: 802.3af / at / 44 to 57V Passive
  • PoE Input Pinout: 1,2(-) 3,6(+) or 7,8(-) 4,5(+)
  • PoE Output: 802.3af or 802.3at Class 4
  • PoE Output Pinout: 1,2(+) 3,6(-) Up to 25W
  • Data Speeds: 10/100/1000Mb
  • Self Consumption Power: 2.0W Typ
  • Operating Temperature: -13°F to 131°F (-25°C to +55°C)
  • Operating Humidity: 0 to 100% RH

CAT5e/CAT6 Cable Loss @ 100m

  • Load  -   Cable Loss
  • 8W    -   0.2W
  • 15W  -   0.7W
  • 20W  -   1.2W
  • 25W  -   2W

More Information

MFRPartNum:
POE-EXT-GD-HP
Datasheet:
