Ubiquiti ENVR Core Enterprise NVR 16 Bay 25G SFP28 Rackmount Redundant Power UniFi Protect

3U UniFi Protect NVR with 16-bay support for 2.5'/3.5' HDDs/SSDs, up to (300) 4K or (500) Full HD cameras, hot-swappable power supplies and optional 16-bay storage expansion units.

Key Features

• (16) 3.5” HDD / SSD Bays
• (2) Storage Expansion Ports
• (2) Hot-Swap Power Supplies
• (2) 25G SFP28 Uplink Ports
• Included Front Bezel

Technical Specification

• Overview:
  • Dimensions: 481.4 x 550 x 132 mm (19 x 21.7 x 5.2')
  • Managed Cameras:
    • (500) HD
    • (400) 2K
    • (300) 4K
  • Managed Access Hubs: 300+
  • Storage Capacity: (16) 3.5' drive bays
  • Data Protection: ✓
  • Vantage Point: ✓
  • Networking Interface:
    • (2) 25G SFP28 ports (25G/10G/1G)
    • (1) GbE MGMT RJ45 port (1G/100M)
  • Expansion Port: (2) SFF-8644 ports (24G)
  • Power Redundancy: ✓
  • Form Factor: Rack Mount (3U)
  • Door Access Support: ✓
  • Management Application:
    • UniFi Protect
    • UniFi Access
• Hardware:
  • Hard Drive Capacity:
    • (16) 2.5/3.5' HDD / SSD support
    • (2) Expansion ports, support up to 48 total HDD/SSD
  • Max. Power Budget for Drives: 313W
  • Max. Power Consumption: 237W
  • Power Method: (2) AC input, 100–240V, 7A Max., 50/60Hz (Redundant, hot-swappable)
  • Power Supply: Hot-swappable 550W CRPS
  • Processor: 128-core Arm® v8.2 at 2.6 GHz
  • Memory: 64 GB
  • Management:
    • Ethernet
    • Bluetooth
  • Weight:
    • Without rails: 20.5 kg (45.2 lb)
    • With rails: 23.4 kg (51.6 lb)
  • Enclosure Material: SGCC steel
  • Mount Material: Aluminum
  • Slide Rails: The rails support 482.6 mm (19') four-post racks with square holes (9.5 x 9.5 mm) and posts depths ranging from 600–1066 mm (23.6–42')
  • Faceplate: Support UACC-3U-Bezel-Lite (Included)
  • LEDs:
    • SFP28: ✓
    • HDD: ✓
    • System: ✓
    • Expansion Port: ✓
    • CRPS: ✓
  • Ambient Operating Temperature: 10 to 35° C (50 to 95° F)
  • Ambient Operating Humidity: 20 to 90% noncondensing
  • NDAA Compliant: ✓
  • Certifications: CE, FCC, IC
• Software:
  • Application Requirements:
    • Mobile App:
      • UniFi Protect iOS™ version 3.3.0 and later
      • UniFi Protect Android™ version 3.2.0 and later
