Ubiquiti U7 Mesh US WiFi 7 Access Point 2.5GbE PoE IPX6 Indoor Outdoor Long Range

Ubiquiti U7-Mesh-US Access Point

Compact indoor/outdoor WiFi 7 AP with integrated long-range antenna system.

Key Features

• Status LED ring
• Long-range directional and omni antennas
• 1,500 ft² coverage
• 200+ connected devices
• Dual-radio WiFi 7 with 4 spatial streams
• Sleek form factor
• Weatherproof IPX6 rating
• Tabletop, wall, pole mount
• Reset button
• 2.5 GbE PoE in RJ45 port

Technical Specification

• Overview:
  • Dimensions: ⌀48.5 x 159.5 mm : (⌀1.9 x 6.3')
  • WiFi Standard: WiFi 7
  • Spatial Streams: 4
  • Coverage Area: 140 m² (1,500 ft²)
  • Max. Client Count: 200+
  • Uplink: 2.5 GbE
  • Mounting: Wall, Pole, Table stand (Mounts included)
  • Weatherproofing: IPX6 (Installed with the outdoor mount)
  • Power Method: PoE
• Performance:
  • MIMO:
    • 5 GHz:2 x 2 (DL/UL MU-MIMO)
    • 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
  • Max. Data Rate:
    • 5 GHz: 4.3 Gbps (BW240)
    • 2.4 GHz: 688 Mbps (BW40)
  • Antenna Gain:
    • 5 GHz:
      • Omnidirectional: 6 dBi
      • Directional: 10 dBi
    • 2.4 GHz: 3 dBi
  • Max. TX Power:
    • 5 GHz:24 dBm
    • 2.4 GHz:23 dBm
  • Max. BSSIDs: 8 per Radio
  • Supported Data Rates:
    • 802.11be (WiFi 7): 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
    • 802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
    • 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
    • 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
• Features:
  • Wireless Meshing: ✓
  • Band Steering: ✓
  • 802.11v BSS Transition Management: ✓
  • 802.11r Fast Roaming: ✓
  • 802.11k Radio Resource Management (RRM): ✓
  • Advanced Radio Management: ✓
  • Passpoint (Hotspot 2.0): ✓
  • Captive Hotspot Portal:
    • Custom Branding Landing Page: ✓
    • Voucher Authentication: ✓
    • Payment-Based Authentication: ✓
    • External Portal Server Support: ✓
    • Password Authentication: ✓
    • Guest Network Isolation: ✓
  • Private Pre-Shared Key (PPSK): ✓
  • WiFi Speed Limiting: ✓
  • Client Device Isolation: ✓
  • WiFi Schedules: ✓
  • RADIUS over TLS (RadSec): ✓
  • Dynamic RADIUS-assigned VLAN: ✓
• Hardware:
  • Max. Power Consumption:13W
  • Includes PoE Adapter: ✓
  • Supported Voltage Range: 42.5–57V DC
  • Networking Interface: (1) 2.5 GbE RJ45 port
  • Weight: 313 g (11 oz)
  • Management: Ethernet
  • Enclosure Material: UV-stabilized polycarbonate
  • Mount Material: UV-stabilized polycarbonate
  • LEDs:
    • System: W/B
  • Channel Bandwidth:HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz)
  • NDAA Compliant: ✓
  • Certifications: CE, FCC, IC
  • Ambient Operating Temperature: -30 to 60° C (-22 to 140° F)
  • Ambient Operating Humidity: 5 to 95% noncondensing
• Software:
  • Application Requirements:
    • UniFi Network: Version 10.1.85 and later
  • Mobile App:
    • UniFi iOS™: Version 10.32.1 and later
    • Android™: Version 10.35.1 and later
