Ubiquiti UACC-Lock-Bolt-Secure Fail-Secure Bolt Lock

Fail-secure electric drop bolt lock. Designed for NO/COM/NC relay wiring with UniFi Access Hub.

Key Features

• Aluminium, steel, or wooden door frame compatible
• LED indicator
• Fail-secure electric drop bolt lock
• Dimensions: 205 mm (height)
• 131.6 mm (body length)
• 45.7 mm (depth)
• 38 mm (width)

Technical Specification

• Overview:
  • Dimensions:
    • Lock body: 132 x 30 x 42 mm (5.2 x 1.2 x 1.7')
    • Door frame plate: 82 x 32 x 3 mm (3.2 x 1.3 x 0.1')
    • Door plate: plate: 204 x 33 x 3 mm (8 x 1.3 x 0.1')
  • Weight:
    • Lock body: 350 g (12.3 oz)
    • Door frame plate: 22 g (0.7 oz)
    • Door plate: 46 g (1.6 oz)
  • Enclosure Material:
    • Lock body: aluminum alloy
    • Door frame plate/Door plate: aluminum alloy
  • Lock Features:
    • Lock Type: Fail secure
    • Support Door Type: Single door (Wooden/metal)
    • DPS: Embedded
    • Current Power: Max. 900mA
    • Support Voltage Range: 12V DC ±10%
    • Wiring:
      • (1) Lock 12V/NO (red)
      • (1) Lock 12V/COM (black)
      • (1) Lock 12V/NC (blue)
      • (1) DPS/- (white)
      • (1) DPS/+ (orange)
    • Mounting: Door frame recess mount
    • LED Indicator:
      • Red: locked
      • Green: unlocked & power indicator
  • Door Status Contact:
    • Type: Dry contact
    • Logic:
      • Door Open:  DPS/+ & DPS/- = Open
      • Door Close:  DPS/+ & DPS/- = Short
    • Rating: Max. 30V DC, 0.5A
  • Ambient Storage Temperature: -20 to 70° C (-4 to 158° F)
  • Ambient Operating Temperature: -10 to 60° C (14 to 140° F)
  • Ambient Operating Humidity: 5 to 90% noncondensing
  • NDAA Compliant: ✓
  • Certifications: FCC, IC, CE
