Ubiquiti

Part:
UBB-XG

Ubiquiti UniFi 10Gbps Building Bridge XG

$1,122.95
$1,199.99
Condition:
New

PRODUCT SPECIFICATIONS

UBB-XG - Ubiquiti Building-To-Building Bridge XG Kit

It comes with two point-to-point bridge modules included. You can connect networks over the 60 GHz band, transferring up to 6 Gb/s across up to 1640 feet.

The bridge modules may be powered using the included PoE injectors, which plug into the Gigabit-speed RJ45 PoE port. There is also an SFP+ port available for up to 10 Gb/s fiber up-links. Precision alignment pole mount kits are included.

Features

  • 500 m (1,640 ft) maximum range
  • 60 GHz & 5 GHz dual-radio redundancy
  • (1) 10G SFP+ and (1) GbE PoE++ port
  • Powered using PoE++* Includes PoE power adapter.
  • IPX6-rated weatherproofing
  • Built-in LED alignment indicators
  • Sold as 2-pack

Note. Cannot be set up standalone and must be managed by a UniFi Console, Official UniFi Hosting, or a Self-Hosted UniFi Network Server.

Technical Description

  • Hardware
    • Networking interface:
      • (1) GbE RJ45 port
      • (1) 1/10G SFP+ port
    • Management interface:
      • Ethernet
      • Bluetooth
    • Power method:
      • PoE++
      • Passive PoE:
        • 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
        • 2-pairs (4, 5+; 7, 8-)
    • Power supply:
      • UniFi PoE switch
      • 48V, 0.65A Gigabit PoE adapter (included)
    • Supported voltage range: 48V DC ± 10%
    • Max. power consumption: 31.2W
    • Maximum range: 500 m (1,640 ft)
    • LEDs: R/G/B
    • Button: Factory-reset
    • Mounting: 60G precision alignment pole mount (Included)
    • Certifications: FCC, IC, CE, terragraph
  • Software
    • Wi-Fi standards: 802.11ac/ad/ay
    • Wireless security: WPA2 AES (Always On)
    • Operating modes: PtP
    • VLAN: Management VLAN only
  • RF
    • Operating frequency*: 57 to 66 GHz (*Dependent on regional regulations.)
    • Channel bandwidth: 2,160/4,320 MHz (Channel Bonding Enabled)
    • Operating channels*: 58,320/59,400/60,480/61,560/62,640/63,720/64,800 MHz (*Dependent on regional regulations.)

More Information

MFRPartNum:
UBB-XG
Datasheet:
