Ubiquiti

Part:
UMR-Industrial-US

Ubiquiti UMR-Industrial-US Mobile Router Ruggedized LTE Cat 4 IoT Router with GPS and PoE

$199.00
Condition:
New

PRODUCT SPECIFICATIONS

Ubiquiti UMR-Industrial-US Mobile Router Industrial

Compact, ruggedized, and carrier unlocked LTE Cat 4 mobile WiFi router designed for indoor/outdoor IoT applications.

Key Features:

  • Site-to-site VPN and VPN client routing
  • (2) GbE ports with (1) PoE output
  • Powered using PoE, USB Type-C, or 4-pin DC power socket
  • Outdoor GPS location tracking
  • Flexible wall, pole, and DIN rail mounting
  • Weatherproof (outdoor exposed) with the included cover
  • Optional Mobility Cloud subscription

Technical Description:

  • Mechanical
    • Dimensions
      • Without antennas and outdoor cover: 114.5 x 93.6 x 32 mm (4.5 x 3.7 x 1.3')
      • With antennas: 213 x 93.6 x 32 mm (83 x 3.7 x 1.3')
      • With antennas and outdoor cover: 217 x 94 x 32 mm (8.5 x 3.7 x 1.3')
    • Weight:
      • Device: 360 g (12.7 oz)
      • Device with outdoor cover: 395 g (13.9 oz)
      • DIN rail/wall mounts: 25 g (0.9 oz)
    • Enclosure material: Polycarbonate, aluminum
    • Mount material: Wall/pole mount: polycarbonate
    • DIN rail mount: polycarbonate
    • Pole mount diameter: 1–2' on pipe outer diameter
    • Wind loading: 38.8 N at 200 km/h (8.7 lbf at 125 mph)
    • Weatherproofing: Device with outdoor cover: IP66
  • Hardware
    • Management interface:
      • Ethernet
      • WiFi
    • Networking interface: (2) GbE RJ45 ports
    • LTE Category 4 radio
    • WiFi 4
    • PoE interface:
      • (1) PoE input
      • (1) PoE output (Max. 10W)
    • Power supply:
      • UniFi PoE switch (48—54V DC)
      • USB Type-C (5V DC)
      • 4-pin ATX DC power socket (9—30V DC)
    • Max. power consumption: 12.5W
    • WiFi standards: 802.11 b/g/n, WiFi 2.4G, 20/40 MHz
    • LED: Status: blue/white
    • Button: Factory reset
    • Mounting: DIN rail/wall/pole mount (Included)
    • Ambient operating temperature: -40 to 70° C (-40 to 158° F)
    • Ambient operating humidity: 5 to 95% noncondensing
    • Certifications: FCC, IC, PTCRB, GCF, AT&T, T-Mobile, Verizon, Wi-Fi Alliance
    •

More Information

MFRPartNum:
UMR-Industrial-US
