Ubiquiti UPL-Port-B-US PoE Audio Port

A digital audio streamer with an ultra-compact, versatile design and an intuitive control system, supporting multiple music streaming services and scalable multi-zone installations.

Key Features

• Wireless music streaming with Apple AirPlay and Spotify Connect
• Status LED on the front
• HDMI eARC port (for TV audio connection)
• Optical digital input
• Optical digital output
• USB-C I/O port
• PoE RJ45 Ethernet port (Power over Ethernet)
• Two RCA analog inputs (Left / Right)
• Two RCA analog outputs (Left / Right)
• Power input

Technical Specification

• Mechanical:
  • Dimensions: 109 x 109 x 40.5 mm  (4.3 x 4.3 x 1.6')
  • Weight: 250 g (8.5 oz)
  • Enclosure Material: Polycarbonate
  • Mounting: Compact Desktop
• Audio:
  • Output: Mono / Stereo sound
  • Surround Format: PCM
  • Zone:  Up to 32 PowerAmps and PoE Audio Ports
  • Audio Input:
    • (2) RCA analog inputs L/R
    • (1) HDMI eARC input
    • (1) Optical In
    • (1) USB-C versatile port
  • Audio Output:
    • (2) RCA analog outputs L/R
    • (1) Optical Out
    • (1) USB-C versatile port
  • Streaming: AirPlay, Spotify Connect, Soundtrack Your Brand
• Hardware:
  • Networking Interface: (1) 10/100 MbE RJ45 port
  • WiFi Standards: 802.11 a/b/g/n/ac/ax
  • Connectivity:
    • WiFi 2.4G, BW 20/40 MHz
    • WiFi 5G, BW 20/40/80 MHz
  • Power Method:
    • (1) AC/DC adapter, 12V DC (Included)
    • (1) PoE
  • Max. Power Consumption: 10W
  • Button: (1) Factory-reset
  • Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
  • Ambient Operating Humidity: 5 to 90% noncondensing
  • NDAA Compliant: ✓
  • Certifications: FCC, IC, CE, Anatel: 07624-25-08356
• Software:
  • Application Requirements: UniFi Play iOS™ and Android™: Version 1.8.0 and later
