PRODUCT SPECIFICATIONS
US-XG-6POE - Managed 10G 6-Port PoE++ Switch
The Ubiquiti UniFi® XG 6POE is a fully managed, multi-gigabit Layer 3 switch designed for high-performance networking with PoE++ capabilities. This switch is equipped with (4) 10GbE RJ45 PoE++ ports and (2) 10G SFP+ ports, providing flexible connectivity options for high-speed networks. Supporting up to 60W per port, the PoE++ capabilities enable the powering of high-demand devices like the UniFi Access Points and BaseStation XG. The US-XG-6POE features advanced Layer 3 functionality, including static routing and inter-VLAN routing, ensuring seamless integration into growing network infrastructures. Additionally, it can be managed via the UniFi Controller software or mobile app, offering centralized control and monitoring.
Features:
- 4 PoE++ RJ45 Ports: Each supports speeds of 1/2.5/5/10 Gbps with 802.3bt PoE++ delivering up to 60W per port.
- 2 SFP+ Ports: For high-speed fiber uplinks at 10 Gbps.
- 60 Gbps Non-Blocking Throughput: Ensures simultaneous traffic processing on all ports without packet loss.
- 120 Gbps Switching Capacity: High switching capacity for handling large data volumes.
- Layer 3 Features: Supports inter-VLAN routing, static routing, and DHCP server functionality for advanced network configurations.
- PoE++ Compatibility: Supports 802.3af/at/bt standards for powering devices such as access points, cameras, and phones.
- Power Redundancy: Can be powered by an external AC/DC adapter or optional DC power input for backup redundancy.
Applications
- Ideal for powering multiple high-demand PoE++ devices like UniFi Access Points (UAP-XG, UAP-AC-SHD) or BaseStation XG in enterprise networks.
- Suitable for businesses requiring multi-gigabit speeds with fiber uplink connectivity for high-capacity data transmission.
Technical Description
- Networking Interfaces:
- (4) 1/2.5/5/10G RJ45 ports with 802.3bt PoE++
- (2) 1/10G SFP+ ports for fiber uplinks
- (1) RJ45 Serial Console port for CLI management
- (1) USB Type-C port for out-of-band management
- Total Non-Blocking Throughput: 60 Gbps
- Switching Capacity: 120 Gbps
- Forwarding Rate: 89.3 Mpps
- Power Supply:
- 54V DC, 3.88A Power Adapter (Included)
- Optional DC input via terminal block for redundancy
- PoE Output:
- Maximum PoE++ wattage per port: 60W
- Total PoE budget: 170W
- Maximum Power Consumption: 40W (excluding PoE output)
- Operating Temperature: -5°C to 45°C (23°F to 113°F)
- Operating Humidity: 5% to 95% non-condensing
- Dimensions: 165 x 268.1 x 31.8 mm (6.50 x 10.56 x 1.25 inches)
- Weight: 1.3 kg (2.87 lbs)
- Certifications: CE, FCC, IC
- Advanced Features
- Layer 3 Switching: Inter-VLAN routing, static routing, DHCP server support.
- PoE++ on All RJ45 Ports: Supports high-power devices with 802.3bt PoE++ on all four RJ45 ports, up to 60W per port.
- UniFi Controller Integration: Manage the switch via the UniFi Controller software for centralized control, monitoring, and configuration.
- Mounting Options: Can be mounted on a desktop or in a rack (rackmount accessory sold separately).
