PRODUCT SPECIFICATIONS
SKU: US-16-XG
Switch XG 16
Ubiquiti Switch XG 16 US-16-XG Layer 2 Aggregation Switch (12) 10G SFP+ ports (4) 10GbE RJ45 ports
Layer 2 aggregation switch with (12) 10G SFP+ ports and (4) 10GbE RJ45 ports.
The Switch XG 16 (US XG 16) is a fully managed, Layer 2 switch with (12) 10G SFP+ ports and (4) 10GbE RJ45 ports. Its 320 Gbps switching capacity and 160 Gbps total, non-blocking line rate make it an ideal aggregation switch for your core network. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
-
10G Aggregation Switch for Enterprise Networks
Build and expand your network with Ubiquiti® UniFi® Switch 16 XG, part of the UniFi Enterprise System. The US-16-XG is a fully managed, 16-port, 10G fiber switch that enhances network capacity by providing high-bandwidth aggregation connectivity to multiple switches in your network.
-
10 Gbps Deployment Example
Supports 12 x US-48, 10 Gbps symmetric (40 Gbps aggregate) uplink/downlink and 4 x 10 Gbps Ethernet for uplink to another US-16-XG or core server.
-
20 Gbps Deployment Example
Supports 6x US-48, 20 Gbps symmetric (40 Gbps aggregate) uplink/downlink and 4 x 10 Gbps Ethernet for uplink to another US-16-XG or core server.
-
10G High-Capacity Links
The US-16-XG offers maximum performance and low latency as an aggregation switch. For fiber connectivity, it features 12 SFP+ ports. For CAT 6/5e cable connectivity, the US-16-XG offers four 10G RJ45 ports.
Product Specifications
-
(12) 1G/10G SFP+ Ports
-
(4) 1G/10G RJ45 Ports
-
(1) RJ45 Serial Console Port
-
Non-Blocking Throughput: 160 Gbps
-
Switching Capacity: 320 Gbps
-
Forwarding Rate: 238.10 Mpps
-
Rack Mountable with Mount Brackets (Included)
-
DC Input Option (Redundant or Stand-Alone)
