Ubiquiti Switch 8 US-8 8-Port Layer 2 PoE Switch Gigabit PoE Passthrough Output
The Ubiquiti US-8 model features Gigabit Ethernet ports in a compact form factor. The switches are fully manageable, delivering robust performance and intelligent switching for your growing networks. The switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. For its total, non-blocking throughput, each supports up to 8 Gbps with a switching capacity of 16 Gbps. This model has a PoE Passthrough port. It's output voltage and power rely directly on then power input.
8-Port Managed Gigabit Switches
The US-8 is a PoE Powered 8-port gigabit switch with PoE Passthrough. Perfect for cleanly adding Ethernet ports where needed, with passthrough to keep your PoE device powered.
The new 8-port models feature Gigabit Ethernet ports in a compact form factor. For its total, non-blocking throughput, each Switch supports up to 8 Gbps.
The Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss, with a switching capacity of 16 Gbps.
- 8 x RJ-45 Gigabit Ethernet Ports
1 x PoE Passthrough Port
8 Gbps Non-Block Throughput
16 Gbps Switching Capacity
11.9 Mpps Forwarding Rate
12 W Maximum Power Consumption
148.0 x 99.5 x 30.7 mm (5.83 x 3.92 x 1.21 ")
422 g (15.24 oz)
Total Non-Blocking Throughput:
Max. Power Consumption:
12W (Excluding PoE Output)
(1) DC 48V or 24V, Max. 1.25A
(1) PoE Input, 802.3af/at (Pins +1,2; -3,6); Passive 24V (Pins +4,5; -7,8)
Supported Voltage Range:
DC: 48V or 24V
48V Mode: 56V to 40V
24V Mode: 27V to 20V
